Omnidirectional Scanner For Supermarket Mini USB Barcode Scanner DTK2098

Name: Omnidirectional Scanner For Supermarket Mini USB Barcode Scanner DTK2098
Brand: Detaik
SKU: 103018271
Availability: InStock

Negotiable MOQ: 5 Pieces (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

Detaik

Model Number:

DTK2098

Shenzhen Detaik Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name Detaik

Model Number DTK2098

Specifications

Mini usb barcode scanner
Omnidirectional Scanner
Number of Scan Lines:20 Lines
Scan Rate:1400 scans per second
Good price

Omnidirectional Scanner For Supermarket Mini USB Barcode Scanner DTK2098

Optical & Performance
Light Source	650nm visible laser diode (VLD)
Depth of Field	0~206mm @ UPC/EAN PCS=90%
Scan Pattern	5 directions of scan field
Number of Scan Lines	20 Lines
Scan Rate	1400 scans per second
Min. Resolution	0.127mm(5mil)@Code 39, PCS=90%
Print Contrast	Min. 30% (UPC/EAN 100%)
Indicators (LED)	Two-color LED (Blue & Red)
Beeper Operation	Programmable tone & volume
System Interfaces	HID USB,USB Virtual COM,RS-232
Physical / Mechanical
Dimension	94mm158.4mm110mm
Weight	340g(Without cable)
Cable Type	Standard 2M straight (replaceable)
Power
Input Voltage	5VDC±10%
Operating Current	220mA
Enviroment Conditions
Operating Temperature	0℃~+50℃
Operating Humidity	5%~95%(non-condensed)
Temperature in Storage	-20℃~+60℃
Ambient Light	0~4,000Lux(fluorescence)
Regulatory
EMC	CE EN55022 B, FCC Part 15 Class B, VCCI, BSMI
Laser Class	CDRH Class IIa, IEC 60825-1 Class 1
Decode Capability
	UPC/EAN/JAN,UPC-A & UPC-E,EAN-8 & EAN-13, JAN-8 &JAN-13, ISBN/ISSN, Code 39 (with full ASCII), Codabar (NW7), Code 128 & EAN 128,Code 93,Interleaved 2 of 5 (ITF),Addendum 2 of 5, IATA Code,MSI/Plessy, China Postal Code,Code 32 (Italian Pharmacode),RSS 14,RSS Limited, RSS Expanded
