High Speed 1575mm Fourdrinier Recycling Machine for Making Writing Paper/A4 Paper/Notebook Paper, Printing Paper Product Machine

High Speed 1575mm Fourdrinier Recycling Machine for Making Writing Paper/A4 Paper.Notebook Paper, Printing Paper Product Machinery Price

Basic Information of Paper Making:

The raw materials of paper production line range from waste paper, virgin pulp, wood pulp board, wheat straw, rice straw, sugarcane bagasse, cotton linter, cotton stalk, reed, for the purpose of making best quality paper. And the raw material could be determined as per customers' needs for the kind of paper they want. Furthermore, the fininshed product of the paper machine is paper roll and paper sheet. Finally, you can obtain the final product you intend to purchase with the paper converting machines.

The paper making machine is composed of the following parts:

1 pulp making production line

2 sizing press part

3 paper making production line

4 paper cutting and packing part

5 boiler

6 hot steam recylcing part

7 spare parts

Technical Parameters:

1.Raw material: reed

2.Output paper style: A4 paper, printing paper, notebook paper,writing paper

3.Capacity: 5T/D;

4.Output paper weight: 60-90g/m2;

5.Net paper width: 1600mm;

6.Width of cylinder: 1950mm

7.Rail gauge:2400mm;

8.Drive way: AC inverter speed adjusting, sectional drive

Raw Materials for Making Printing Paper/A4 Paper/Notebook Paper:

Main Structures of Model 1575mm:

1 Wire part: 10.83m X 2m  fourdrinier part: 1 set. Wire table weld by steel plate and surface wrapped by stainless steel.

2 Press part: 550mm×1950mm×2400mm natural marble roll: 1 piece,500mm×1950mm×2400mm rubber roll: 1piece with rubber shore hardness 92±2, equipped with pneumatic pressure device.

3 Dryer part: first dryer part: 2000mm×1950mm×2400mm  dryer cylinder: 1piece,500mm×1950mm×2400mm touch roll: 1piece with pneumatic pressure device.dryer group part: 1500mm×1950mm ×2400mm dryer cylinders 2pcs,with wire dry device, 3pcs of scraper blades.Dryer exhaust hood 1 group.Arrangement mode:1+press part+2.

4 Calendering part: equipped with 1 set of 1575mm three rolls calender,bottom roll 450mm×1950mm×2400mm,middle roll 300mm×1950mm×2400mm,upper roll 400mm×1950mm×2400mm .

5 Winding part: 1575mm horizontal pneumatic winding machine:1 set

5 Rewinding part: ordinary rewinder: 1set

Equipment List:

Flow Chart for 1575mm Fourdrinier Printing Paper/A4 Paper/Notebook Paper Making Machinery:

After-sales services:

 1)   Fast & Safe Delivery;

 2)  Assisting our clients for foundation construction of equipments;

 3)  Dispatching engineers to install and debug equipments;

 4)  Training the first-line operators on site;

 5)  Providing life-long maintenance service;

 6)  Providing technical exchanging;

 7) Arranging technicians to install and test the machine for you and training your workers;

 8) One year guarantee time after running of the machine;

9)  Supply you spare parts at a competitive price for a long time.

Packaging & Shipping:

We are the professional Chinese manufacturer in the field of paper making machine,  our products covers pulp making equipment, toilet paper machine, kraft paper machine, corrugated paper machine, A4 paper machine, paper coating paper and paper deep processing machine the related spare parts.

We are able to design and work out the production line that meet customers' needs.

Our products have been exported to many countries and regions, such as America, Egypt, India, Fiji, Iran, Ghana ,Paraguay, Russia, Syria,Pakistan, Tanzania, Angola, Rwanda, Brazil, Armenia and so on,

Our products and services have won customers’ consistent affirmations.
