Home > Electrical & Electronics > Telecommunication & Broadcasting > Radio & TV Broadcasting > Single Channel Fixed Modulator / CATV Modulator
Negotiable
MOQ: 10 Sets (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
Detaik
Model Number:
JM-518
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Super MINI 1 Channel Fixed Modulator / CATV ModulatorNegotiableMOQ: 10 Sets -
JM-50168 16 in 1 Fixed Adjacent Modulator NTSC PAL Telecommunication CATV Modulator DemodulatorNegotiableMOQ: 1 Piece
-
JM-50168 Fixed Adjacent Frequency Modulator Demodulator CATV Headend SAW Filtered TV ModulatorNegotiableMOQ: 1 Piece
-
CATV Modulator 4 Channels in One Modulator Audio Frequency Pitch KHz 6500US$ 1 - 500MOQ: 1 Set
-
CATV Modulator 4 Channels Agile Modulator in One Modulator Audio Frequency Pitch KHz 6500NegotiableMOQ: 1 Set
Place of Origin
Guangdong, China
Brand Name
Detaik
Model Number
JM-518
Specifications
Sigle Channel Fixed Modulator*Steady and Reliable
*High Quality
*Direct Factory Price
*With One Year Warranty
Single Channel Fixed Modulator / CATV Modulator
Specifications:
reflection | Output frequency range | 45-870MHz |
frequency accuracy | ±5KHz | |
output level | 113dBmV | |
out of band suppression | ≥ 60dB | |
side-band suppression | ≥ 60dB | |
output impedance | 75Ω | |
video to audio carrier ratio | -10dB ~ -20dB | |
video frequency | input level | 0.6 ~ 1.5Vp-p |
input impedance | 75Ω | |
input reflection | 30dB min | |
k coefficient | 4 % max 2T pulse | |
video s/n | 50dB( no emphasis ) | |
C/L delay | 40nsec | |
frequency response | ± 1dB 25Hz ~ 5.8MHz | |
differential gain | ± 4 % modulation 87.5 | |
differential phase | ± 4 ° | |
audio frequency | input level | -10 ~ 10 dBm |
input impedance | 10KΩ min | |
frequency response | ± 1dB max40Hz ~ 15KHz | |
distortion | 0.5 % | |
signal to noise ratio | 60dB | |
audio picture interval | according to the TV system standard | |
power supply |
Voltage
| 220V or 110V |
