Home > Computer Products > Industrial Computer & Accessories > Industrial Computer > Industrial Full-size CPU Card With Intel G41 (LPCA-G41 )

Industrial Full-size CPU Card With Intel G41 (LPCA-G41 )

Industrial Full-size CPU Card With Intel G41 (LPCA-G41 ) thumbnail-1
Industrial Full-size CPU Card With Intel G41 (LPCA-G41 ) photo-1
US$ 100 - 138 MOQ: 1 Piece
Key Specifications
Get Latest Price
Products Status:
Stock
Type:
Embedded Industrial Motherboard
Brand Name:
LingJiang
Contact Supplier Request Quote Chat Now
Shenzhen Ling Jiang Computer Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
ShenZhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Products Status Stock
Type Embedded Industrial Motherboard
Brand Name LingJiang
Model Number LPCA-G41
Place of Origin Guangdong, China

Specifications

1.Dual-channel DDR3 800/1066MHz supports up to 8 GB
2.2xRS-232 4xSATAII with Intel RAID0,1,5 and 10
,8 x USB,8-bit digital I/O

industrial Full-size CPU Card with intel G41 (LPCA-G41 )industrial Full-size CPU Card with intel G41 (LPCA-G41 )

features:

1.PICMG 1.0 form factor

2. LGA775 Intel  Core 2 Extreme/Quad/Duo and Celeron  processor supports up to

1333 MHz FSB

3. Dual-channel DDR3 800/1066MHz supports up to 8 GB

4. High performance PCI Express Gigabit Ethernet controller

5. Four SATA II with Intel  Matrix Storage Manager support Raid 0, 1, 5 and 10

6. LingJiang One Key Recovery solution allows you to create rapid OS backup and recovery



Specification

CPU:LGA 775 Intel  Core 2 Extreme/Quad/Duo, Celeron with a 1333/1066/800MHz FSB support

System Chipset:Intel  G41+ ICH7R

BIOS:AMI bios

Ethernet:Dual PCIe Realtek 8111CP GbE controller

I/O Interface:2 x RS-232 1 x IDE 1 x LPT 1 x FDD

1 x KB/MS by 6-pin header

4 x SATAII with Intel RAID 0,1,5 and 10

8 x USB 2.0 (2 on bracket, 4 by pin header, 2 to backplane via Golden Finger)

Digital I/O:8-bit digital I/O, 4 input/ 4 output

Super I/O:ITE IT8718F

Infrared:1 x Infrared by 5-pin pin header

Audio:5.1 channel audio kit with Realtek ALC655 AC'97 codec
7.1 channel HD audio kit with Realtek ALC883 codec supports dual audio streams

Display Interfaces:Intel GMA X4500
VGA display output up to 2048x1536

Watchdog Timer:supports 1~255 sec. System reset

Power Supply:ATX Power

Power Consumption:3.3V 0.53A, 5V 6.2A, 12V 0.11A, Vcore_12V  2.91A (Intel Core 2 Duo E8500 3.16GHz 1333MHz FSB CPU with 2x2GB DDR3 1333MHz)

Temperature:operation: -10°C ~ 70°C

Humidity:operation: 5% ~ 95% non-condensing

Dimensions:338 mm x 126 mm
