Home > Transportation > Cargo & Storage > Storage Racks > Long Span Shelving Rack

Long Span Shelving Rack

Name: Long Span Shelving Rack
Brand: XIANFU
SKU: 102992645
Availability: InStock

US$ 80 - 150 MOQ: 20 Sets

Key Specifications

Get Latest Price

Place of Origin:

Zhejiang, China

Brand Name:

XIANFU

Model Number:

HP011

Contact Supplier Request Quote Chat Now

Ningbo Xianfu Metal Products Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

NINGBO

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Zhejiang, China

Brand Name XIANFU

Model Number HP011

Type Selective Pallet Rack

Material Steel

Feature Corrosion Protection

Use Warehouse Rack

Certification Other

Depth 1.5

Weight Capacity 300-500kgs

Width 600

Height 1800

Specifications

Long span shelving rack
1), Bearing between 300-600 kg/layer;
2), The height of each layer can be adjusted by pitch 50mm;

Long span shelving rack

1), Usually bearing between 300-600 kg/layer;

2), The height of each layer can be adjusted by pitch 50mm freely;
3), Consist of colume, beam, horizontal brace, diagonal brace and shelving and other accessory;
4), Adopt the structure that the beam hitching on the frame;
5), Steel shelving, wire decks or wooden panel are all available;
6), Easy to installation and disassemble;
7), Surface treatment: Plastic coating;
8), Packing: Neutral paper box or in bulk or upon client's requirements;
9), Different size available;

Bulk Rack (Wide Span Shelving)
Upright Frame All Welded Upright Column: 2''x1.25'', 50.8x31.8x1.5mm Thickness: 1.5mm, 16 Guage				Step Beam Section: 2'' or 3'', Thickness: 1.5mm, 16 Guage
Item	Size (D x H)	Weight (LBS)	Load (LBS)	Item	Size (H x L)	Weight (LBS)	Load (LBS)
CU18072	18" x 72"	18	8800	CB2048	2" x 48"	7	1780
CU18096	18" x 96"	22	8800	CB2072	2" x 72"	10	1322
CU18120	18" x 120"	28	8800	CB2096	2" x 96"	13	880
CU24072	24" x 72"	19	7720	CB3048	3" x 48"	9	2640
CU24096	24" x 96"	24	7720	CB3072	3" x 72"	13	2200
CU24120	24" x 120"	29	7720	CB3096	3" x 96"	16	1760
CU36072	36" x 72"	23	6620	Safely Support Section: 1''x1'', 16 Guage 25.4x25.4x1.5mm
CU36096	36" x 96"	27	6620	Item	Size(L)	Weight (LBS)
CU36120	36" x 120"	29	6620	Item	Size(L)	Weight (LBS)
CU48072	48" x 72"	27	5520	CSS24	24"	1.4
CU48096	48" x 96"	31	5520	CSS36	36"	2.1
CU48120	48" x 120"	35	5520	CSS48	48"	2.7
