High-Pressure Inflatable Tyre Inspection Machine

Specifications

The machine is used to inspect the internal air tightness of retreading tyres and check the tyre interiors for air leaks.

Function:

High-Pressure Inflatable Tyre Inspection Machine YLYQ-1200 is used to inspect the internal air tightness of retreading tyres and check the tyre interiors for air leaks. Through inflating the effective air pressure of tyre, observe the tyre changes.

Features:

1. Tyre is rotated by a variable speed reducer to be easy controled between 1.9~10r/min.
2. With video monitors to observe tyre 360°from all directions.
3. Inflation pressure is as high as 12 Kg/ cm² to put an end to bad tyre so as to make sure tyre quality.
4. Reliable computer control, being easy to write, record and print tyre size, serial number, inflation curve and inspection data.
5. Compressed air door closing unit makes sure operator safety.
6. A mini printer can print all the inspection data onto a paste tab which will be then sticked on tyre.
7. Maximumly lessen the tyre recall from market so as to satisfy tyre user.
8. Control system with a human friend interface enables an easy operation without training.

Specifications:

Model	YLYQ-1200
Tire Size Range	rim 15in---22.5in
Maximum tyre Diameter	≤1260mm
High Air Pressure inspection	≤1.6Mpa
Low Air Pressure inspection	≤0.2Mpa
Cylinder working pressure	0.6—0.75Mpa
Tyre Speed(infinitely variable speed)	0—6.5r /min
Motor power	0.55Kw
Remote Monitoring	3 Cameras
Data Save Life	permanence
Compressed Air Resource Pressure	1.3Mpa
Power Supply	AC380v AC220v 50Hz
Dimension(mm)	2600*1950*2200
Weight(kg)	About 2600
