CT3000 Evenness Tester
CT3000 Evenness Tester
|
Capacitance test |
Capacitive measuring slots:four |
| Testing range:1tex~12ktex | |
| Coefficient of Variation:CV% or U% value testing range: 0.01%~99.99% | |
| Faults value:thin places -30%, -40%, -50%, -60% | |
| thick places +35%, +50%, +70%, +100% | |
| neps +140%, +200%, +280%, +400% | |
| The spectrum analysis range: ordinary spectrogram measurable wave-length range 1cm~2937m | |
| spectrum channels 170 | |
|
fine spectrogram measurable wave-length range cm~2937m spectrum channels 340 | |
| Aberrance-the length of the curve cutting length range:1cm~1472m | |
|
linear density frequency distribution graph:two linear density frequency distribution graphs, | |
| one is within the range of -100%~+100%, one is beyond the range of +100% | |
| drift rate-Threshold figure:reference length is given1cm,10cm,20cm,50cm,1m, | |
| the threshold is 0 ~ 50% of the positive and negative deviation rate curve | |
|
Photoelectric test index |
Diameter D test range:≤3mm |
| Coefficient of VariationCVD%testing range:0.01%~99.99% | |
| Faults value:thin placesD 2mm~16mm,-60%~-30% | |
| thick placesD 2mm~16mm,+35%~+100% | |
|
Hairiness testing |
Testing range:1tex~160ktex |
| Hairiness richness and change:H,SH | |
| The spectrum analysis range:1cm~1472m(170 channels) | |
| Aberrance-the length of the curve cutting length range:1cm~1472m | |
| drift rate-threshold figure:reference length is given1cm,10cm,20cm,50cm,1m, | |
| the threshold is 0 ~ 50% of the positive and negative deviation rate curve |
FAQ
1.Transportation:
Transportation will be launched about 10 days after receiving the payment of the instrument.
2.After-sale Service:
No maintenance cost during ONE year warranty.And we guarantee the southeast
Asia and the central Asia company once a year
3.Installation of New instrument
It is depending on the complexity of the instrument and the technology of the local technological staff.
4.What if the voltage different with China?
We considered that the foreign countries'plugs and the voltage is different with the plugs and voltage in China,we can provide a booster or a buck converter for the foreign buyers.
5.Others
In order to ensure that buyers can using the facilities and simple maintenance,Chang-ling txtile company will provide the place and the trainning resources for free for foreign buyers communicate and study in Changling.
