Professional cotton yarn tension machine tension tester
testing equipment/machines
| Testing principle | constant rate of extension (CRE) |
| Sample length | 500mm±1mm |
| Force testing range | 0~5000cN, sensitivity<1.5cN |
| Elongation range | 0~250mm, error<±1mm |
| Tension speed range | 50mm/min~5000mm/min |
| Pre-tension range | 2cN~150cN |
| Interval sampling length |
0~100m |
| Testing contents | 1~100 time/tube, 1~40 tube/group, total numbers ≤2000 |
| Output index | breaking strength, breaking elongation rate, breaking time, |
| breaking work, breaking intensity, tension CV value, elongation | |
| CV value, max tension and elongation value, min tension and elongation value, | |
| minimal quintic average, fiducial interval,spline graph, splattering | |
| graph,histogram and breaking strength correction, etc. | |
| Power supply | voltage AC220V±10% |
| frequency 50Hz±5% | |
| power consumption ≤400W | |
| Environment | temperature 20℃±10℃ |
| humidity 60±15%RH |
testing equipment/machines
testing equipment/machines
testing equipment/machines
testing equipment/machines
FAQ
1.Transportation:
Transportation will be launched about 10 days after receiving the payment of the instrument.
2.After-sale Service:
No maintenance cost during ONE year warranty.And we guarantee the southeast
Asia and the central Asia company once a year
3.Installation of New instrument
It is depending on the complexity of the instrument and the technology of the local technological staff.
4.What if the voltage different with China?
We considered that the foreign countries'plugs and the voltage is different with the plugs and voltage in China,we can provide a booster or a buck converter for the foreign buyers.
5.Others
In order to ensure that buyers can using the facilities and simple maintenance,Chang-ling txtile company will provide the place and the trainning resources for free for foreign buyers communicate and study in Changling.
testing equipment/machines
testing equipment/machines
