Specifications
wind turbine 10 kw china1.certification: CE
2.low cost but high efficiency
3.quick delivery.
1kw 2kw 3kw 5kw wind turbine 10 kw,dynamo alternator,generator with no motor,china
Feature
1)Minimal maintenance and easy install
2)Good sealing, anti-corrosion
3)work smoothly and steady
4)On-grid and off-grid system
5)Automatically adjust the facing with direction
6)starting with low wind speed
7)wind energy utilization hig
Product information( wind turbine 10 kw )
| 10kw Vertical Axis Wind Turbine Generator OFF-GRID | |
| Power | 10,000W |
| Type of generator | Permanent-magnet 240v A.C. |
| Rotor diameter: | 5.5m |
| Blade Material: | FRP (Fiber glass reinforced*5) |
| Rated rotor speed | 90r/min |
| Rated speed | 12m/s |
| Rated Power | 10,000W |
| Max Power | 12,000w |
| Start up wind speed | 3(m/s) |
| Work speed | 3-25(m/s) |
| Security wind speed | 40(m/s) |
| Height of guy cable tower | 12m |
| Top quality except tower | 750kg |
| Output controller system | Controller , Inverter |
Application
Our FDV-300 watt vertical wind turbine can supply power for charging stations, water TV, washing machines, computers, lighting and other household appliances.
Main export markets:
Eastern Europe
.North America
.western Europe
. Asia
Company Profiles
Our company is a manufacture enterprise which develops, manufactures and sells small and medium complete set of wind turbine. Normally we produce the vertical axis and the horizontal axis wind-driven generator
Pure sine wave inverter
1. Pure sine wave output can drive any household appliances.
2. Use integrated circuit, less wire connection.
3. Adopting micro-processor technology, improving system integration.
4. Excellent protection includes over voltage shutdown, under voltage shutdown, over load protection, short circuit protection, over thermal protection, etc.
5. Be able to work in wind power or wind&solar hybrid system
6. With high efficiency transformer instead of high frequency e-circuit design
7. Automatic regulate voltage.
8. LCD display operation status.
9. High running stability and reliability.
10. True sine wave form power output.
11. High efficient transformer isolation.
12. Buzzer alarm while over-loading/voltage, high-temperature.
Micro-computer intelligence controller
1.If the system meet problem ,and the wind turbine is running ,it can prevent the wind turbine race rotation .
2.have the auto-protection function of the batteries Reverse protection, anti-disconnect battery protection, battery damage protection.
3.when the charge current is high in strong wind,controller can load the wind turbine automatically. And charging the battery with low current.
4.The wind turbine brake automatically when the battery bank voltage get to rated voltage 125%; and stop charging the batteries.
5.the wind turbine get back charging the batteries when the the battery bank voltage get to rated voltage 108%
6.Controller with a manual emergency brake switch, users can use depending on the circumstances. Using this switch, the wind generator be brake.
wind turbine 10 kw Detail parts pictures
NOTE:
1. Tower type and tower height can be changed as per your request
2.Working voltage can be specially designed according to your request
3. For the powrer curve and detail, please feel free to contact us.
