Multipurpose on off Slide Electric Breaker

Multipurpose on off Slide Electric Breaker photo-1
Negotiable MOQ: 1000 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
electric breaker
Model Number:
SK-24D04(2P2T)
Payment & Shipping
Payment Methods:
Port of Shipment:
FOB Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Guangdong, China
Brand Name electric breaker
Model Number SK-24D04(2P2T)
Type Other, Mini, electric breaker
Poles Number 2

Specifications

1.Multipurpose on off slide electric breaker
2.Material:Cu
3.Rating:50V 0.5A
4.Certification:CE,CCC
5.Color:white

Multipurpose on off slide electric breaker



Multipurpose on off slide electric breaker









Multipurpose on off slide electric breaker









Multipurpose on off slide electric breaker









Multipurpose on off slide electric breaker









Multipurpose on off slide electric breaker









Actuator (non-lighted): Nylon 66 94V-2
Actuator (lighted):Polycarbonate
Case:Nylon 66 94V-2
Spring:Steel Wire
Contacts:Silver Alloy
Movable Arm:Silver-Plated Copper Alloy
Terminals:Tin-Plated Copper Alloy
SPECIFICATIONS
Ratings:

0.5a 50v

Electrical Life at Rated Load10,000 (VDE)
6,000 (UL)
Dielectric Strength250vac/min
Insulation Resistance:100MΩ min
Initial Contact Resistance: 0.05Ω max
Temperature Range:-20°C to +70°C
  • High current rating to 20 amps
  • New style with rounded corners
  • Lighted and non-lighted
  • Maintain-action and momentary
  • Available in a variety of colors
  • Mechanical life: min. 50,000 operations
