S(G)B10-100-2500/10 Series Dry Type Electronic Power Transformer

S(G)B10-100-2500/10 Series Dry Type Electronic Power Transformer thumbnail-1
S(G)B10-100-2500/10 Series Dry Type Electronic Power Transformer thumbnail-2
S(G)B10-100-2500/10 Series Dry Type Electronic Power Transformer thumbnail-3
S(G)B10-100-2500/10 Series Dry Type Electronic Power Transformer thumbnail-4
S(G)B10-100-2500/10 Series Dry Type Electronic Power Transformer thumbnail-5
S(G)B10-100-2500/10 Series Dry Type Electronic Power Transformer thumbnail-6
S(G)B10-100-2500/10 Series Dry Type Electronic Power Transformer photo-1
S(G)B10-100-2500/10 Series Dry Type Electronic Power Transformer photo-2
S(G)B10-100-2500/10 Series Dry Type Electronic Power Transformer photo-3
S(G)B10-100-2500/10 Series Dry Type Electronic Power Transformer photo-4
S(G)B10-100-2500/10 Series Dry Type Electronic Power Transformer photo-5
S(G)B10-100-2500/10 Series Dry Type Electronic Power Transformer photo-6
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
Jsrik
Model Number:
SC(B)10-10kV
Contact Supplier Request Quote Chat Now
Jiangshan Rik Import & Export Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
NINGBO/SHANGHAI
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Zhejiang, China
Brand Name Jsrik
Model Number SC(B)10-10kV
Usage Power
Phase Three
Coil Structure Toroidal
Coil Number Autotransformer
Product Description

S(G)B10-100-2500/10 series Dry type Electronic Power Transformer

dry transformer cast resin transformer epoxy resin cast transformer
1 SC(B) series epoxy resin cast dry transformer is cast under vacuum with thin insulating bands automatically .
2 Dry transformer coil is reinforced with glass fiber and cast under vacuum with filler epoxy resin.
3 Have good mechanical properties, is free of crack and has low local discharge, high reliability, and long service life
4 Flame retardancy , explosion-proof and no environmental contamination.
5 Dry transformer resin will not generate toxic or harmful gas under high temperature.
6 Dry transformer highly withstands short-circuit and lightning impact.
7 Small in volume, light in weight, safe in running and free of maintenance.
8 Dry transformer As per users’ requirements the transformer may be provided with casing and blower fan.

You may like
S(G)B10-100-2500/10 series Dry type Electronic Power Transformer S(G)B10-100-2500/10 series Dry type Electronic Power Transformer S(G)B10-100-2500/10 series Dry type Electronic Power Transformer
S(G)B10-100-2500/10 series Dry type Electronic Power Transformer S(G)B10-100-2500/10 series Dry type Electronic Power Transformer S(G)B10-100-2500/10 series Dry type Electronic Power Transformer
Technical parameter



Dry transformer Main Technical parameters for 20kV level, SC(B)9, SC(B)10-50~2500 type



Rated power
(kVA)
High Voltage
(kV)
H.V Tap range
Low Voltage
(kV)
Connection Symbol
Short-Circuit Impedance
(%)
No-load Loss
(W)
On-Load Loss
(W)
No-load Current
(%)
9 Type 10 Type 11 Type 9 Type 10 Type 11 Type
30 6
6.3
10
10.5		 ±5%
±2×2.5%		 0.4 Dyn11
Yyn0		 4 130 110 100 600 600 600 2.1
50 170 150 130 870 870 870 2
63 200 180 150 1040 1040 1040 1.9
80 250 200 180 1250 1250 1250 1.8
100 290 230 200 1500 1500 1500 1.6
125 340 270 240 1800 1800 1800 1.5
160 400 310 280 2200 2200 2200 1.4
200 480 380 340 2600 2600 2600 1.2
250 560 460 400 3050 3050 3050 1.2
315 670 540 480 3650 3650 3650 1.1
400 800 650 570 4300 4300 4300 1
500 960 780 680 5150 5150 5150 1
630 4.5 1200 920 810 6200 6200 6200 0.9
800 1400 1120 980 7500 7500 7500 0.8
1000 1700 1320 1150 10300 10300 10300 0.7
1250 1950 1560 1360 12000 12000 12000 0.6
1600 2400 1880 1640 14500 14500 14500 0.6
2000 5 2830 2270 1940 17140 17140 17140 0.6
2500 3350 2690 2300 20260 20260 20260 0.5



Company Information

S(G)B10-100-2500/10 series Dry type Electronic Power Transformer

S(G)B10-100-2500/10 series Dry type Electronic Power Transformer S(G)B10-100-2500/10 series Dry type Electronic Power Transformer S(G)B10-100-2500/10 series Dry type Electronic Power Transformer
S(G)B10-100-2500/10 series Dry type Electronic Power Transformer S(G)B10-100-2500/10 series Dry type Electronic Power Transformer S(G)B10-100-2500/10 series Dry type Electronic Power Transformer





Our Services



Our Best Service For You

1. Pre sale service
a. make technical solution
b. send quotation, technical data sheet and drawing
c. prepare power transmission plan, testing plan,and shipment plan
2. In sale service
a. supervise the manufacturing schedule totally in accordance with the plan
b. send photos to customer during every manufacturing process(hold point)
c. inform the customer one week before testinng.
3. After sale service
a. installation and commissioning, training the workers
b. quick response within 12 hours any time
c. provide 12 months gurantee period normally.



FAQ



1. Q: What is your minimum order quantity?
A: 1 set.



2. Q: What is your delivery time ?
A: Depend on the type of transformer.



3. Q: What is your payment term?
A: 30% advance by T/T , 70% before delivery by T/T or L/C
or we can discuss about it.



4. Q: What kind of starndard you follow?
A: IEC, ANSI, CSA, GB, etc



5. Q:What is your normal wanrranty period?
A: 12 months after transformer operation.



6. Q: Can u do installation and commissioningin user's site?
A: Yes, we can send our installation team to user's country for service.



7. Q: Do you have any experience in this kind of transformer?
A: Yes, we can provide reference list for check.



8. Q: Are you manufacturer or trading company?
A: Manufacturer and Trading company.
