Angular Contact Ball Bearing 7320ACM 7322ACM 7324CM
Product Name |
Angular Contact Ball Bearing 7320ACM 7322ACM 7324CM |
Brand |
LYDC |
Series |
7300Series |
Model |
7320ACM 7322ACM 7324CM |
Type |
Ball bearing |
Bore Size(mm) |
215-255 |
Outside Diameter(mm) |
100-120 |
Cage |
Steel |
Number of row |
Single row |
Precision |
P0, P6, P5, |
Seal Type |
Open or your required |
OEM Service |
Available |
Sample |
Available |
Stock |
In stoc |
Single row angular contact ball bearings: 78 XX, 79 XX, 70 XX, 72 XX, 73 XX, 74 XX
Double row angular contact ball bearings: 32**, 33**, 38**, 39**, 30**, 52**, 53**,
Four point contact bearings: QJ series
Type of angular contact ball bearings:a=15 °7000C
a=25 °7000AC
a=40 °7000B
1.We can change the rubbersealcolor according to your actual requirements.
2.Customized the marks based on your requirements.
3.Choose the different package to your needs.
Features & Benefits of Angular Contact Bearings
- High axial load carrying capacity in one direction
- Radial load carrying capacity
- High speed capacity
- Low maintenance
- Low heat generation
- Quiet runni
Application
Angular contact ball bearings are engineered for use in high-speed, high precision
applications for: Oil pump, roots blower, air compressor, all kinds of transmission,
fuel injection pump, printing machines.
Product Overviews
A part of Angular Contact Ball Bearing
| 7316C | 36316 | 80×170×39 | 3.6 |
| 7316AC | 36316F | 80×170×39 | 3.95 |
| 7317C | 36317 | 85×180×41 | 4.3 |
| 7317CJ | 36317F | 85×180×41 | 4.97 |
| 7318C | 36318 | 90×190×43 | 5 |
| 7318CJ | 36318F | 90×190×43 | 4.99 |
| 7318CM | 36318 | 90×190×43 | 5.79 |
| 7318C | 36318J | 90×190×43 | 4.92 |
| 7318CM | 36318H | 90×190×43 | 5.64 |
| 7319C | 36319 | 95×200×45 | 5.7 |
| 7319CM | 36319 | 95×200×45 | 6.67 |
| 7319CM | 36319H | 95×200×45 | 6.73 |
| 7320C | 36320 | 100×215×47 | 7.6 |
| 7320CM | 36320H | 100×215×47 | 8.54 |
| 7320CJ | 36320F | 100×215×47 | 7.24 |
| 7321C | 36321 | 105×225×49 | - |
| 7322C | 36322 | 110×240×50 | 11.266 |
| 7322CM | 36322H | 110×240×50 | 11.35 |
| 7324C | 36324 | 120×260×50 | - |
| 7324CM | 36324H | 120×260×50 | 13.5 |
| 7326C | 36326 | 130×280×58 | 17.4 |
| 7328C | 36328 | 140×300×62 | 21.5 |
| 7330C | 36330 | 150×320×65 | 25.1 |
| 7332C | 36332 | 160×340×68 | 30.2 |
| 7334C | 36334 | 170×360×72 | 35.7 |
| 7336C | 36336 | 180×380×75 | 41.3 |
| 7338C | 36338 | 190×400×78 | 47.6 |
| 7340C | 36340 | 200×420×80 | 53.7 |
Packaging
Delivery Details:10-30 days
| Ball Bearing | Deep Groove Ball Bearing |
60 **,618 ** (1008), 619**(1009),62 **, 63 **, 64 **, 160 **(70001 ) |
| Thrust Ball Bearing | 511 ** (81) ,512 **(82) ,513 (83) ,514 ** (84) series and Angular Contact Thrust all Bearings like: 5617 ** (1687) ,5691 ** (91681), 5692 ** (91682) series |
|
| Angular Contact Ball bearing | SN718 **(11068 ) ,70 ** 72 **,73 **, and B (66), C (36), AC (46) series ; otherwise include QJ and QJF series |
|
| Roller Bearing | Spherical Roller bearing | 239**, 230**,240**, 231**, 241**, 222**, 232**, 223**, 233**, 213**, 238**, 248**, 249**and special series include 26** i.e 2638 (3738), 2644 (3844) and so on |
| Taper Roller Bearing | 329**(20079),210**(71), 320**(20071),302**(72), 322**(75), 303**(73), 313**(273),323**(76), 3519**(10979), 3529**(20979),3510**(971), 3520**(20971),3511**(10977), 3521**(20977), 3522**(975), 319**(10076),3819**(10779),3829**(20779), 3810**(777,771), 3820**(20771), 3811**(10777,777) for example: 77752, 77788, 77779 and also include Inch series bearings suchas 938/932 single and double row i.e M255410CD etc. |
|
| Thrust Roller Bearing | 292**(90392), 293**(90393),294**(90394),994**(90194), and 9069 series. |
|
| Cylindrical Roller Bearing | NU10**, NU2**,NU22**, NU3**,NU23**, NU4**, N, NJ ,NUP series as well as NB, NN, NNU series of big bearings, and we also have Split Bearings 412740, 422740 used in cement industry.And FC, FCD series used inSteel Industry. |
Who we are?
Wuhan East Technology Co., Ltd. was established in Hubei in 2007, is specialized in
producing and exporting all kinds of bearings. Our bearings’ quality is always under
strict control. Our factory has the most advanced production facilities and we can also
provide custom-made for various non-standard bearings as per your requirements.We
will try our best to serve you and hope to become one of your friends and business partners.
Why choose us?
1.Over 20 years bearing products manufacturing experience.
2.High quality and reasonable price.
3.Various sizes of bearing are available.
4.We can offer free sample.
5.Fast delivery.
6.Quick respond to your inquiry all the time.
7.We can offer OEM Service
8.We are manufacturer&export company.
1.Could you supply sample for free?
Yes, we can supply sample for free, but need our customer afford freight.
2.Could you tell me the delivery time of your goods?
3-7 days stock goods and other goods according to the quantity about 3-30 days.
3.Can we customize the bearings?
Yes, sure. We can customize the bearings as your requirements.
4.How does your factory do regarding quality control?
Quality first is our principle.We always attach great importance to quality control from the
every beginning to the end of the production. Every product will be fully
assembled and carefully tested
