Specifications
1 Kind:glass mesh 4x4,5x5,6x6,7x7...2 Size:width 1 m, length 800 m to 3000 m
3 Usage:SBS.APP...
4 Weight: 70gsm to 200gsm
+++++++++++++++++++++company introduction++++++++++++++++++++++++++++++++++++
We are a big Chinese manufacturer, our product include compound base(glass-fiber reinforced) and polyester mat for waterproof membrane, the total output is more than 100,000,000 sqm annual, so we can deliver product in time. We are an important OEM partner for Germany Freudenberg and they sell our products to many countries.
Our polyester felt product have the same performance as the product of Johns Manville company. The result is tested in lab of Oriental Yuhong Waterproof company which is the biggest waterproof membrane manufacturer in China.
Our customer include many other famous company, such as Russia Technonicol and France Soprema.
++++++++++++++++++++certificate++++++++++++++++++++++++++++++++++++++++++++++
+++++++++++++++++++++product description++++++++++++++++++++++++++++++++++++++
Fiberglass combination non-woven base mat is one kind of base mat of poly-cotton nonwoven and fiberglass mesh combination. It is made by compounding some density fiberglass when producing non-woven, through drying in high temperature and finalizing technics. It is the basic mat for producing APP/SBS waterproof material.
+++++++++++++++++++++product technical data sheet++++++++++++++++++++++++++++++++
| ITEMS | performance | |||||||
| 4*4 | 5*5 | 6*6 | 7*7 | 8*8 | two-layer 6*6 | |||
| mass per unit area(g/m2) | 70 | 85 | 105 | 105 | 120 | 130 | ||
| mass coefficient of variation per unit area | 10% | 10% | 10% | 10% | 10% | 10% | ||
| horizontal tension(N/50mm) | 100 | 150 | 200 | 450 | 550 | 600 | ||
| longitudinal tension(N/50mm) | 250 | 350 | 400 | 500 | 600 | 700 | ||
| elongation at break | 2% | 2% | 2% | 2% | 2% | 2% | ||
| horizontal tear strength(N) | 100 | 150 | 150 | 300 | 350 | 400 | ||
| longitudinal tear strength(N) | 200 | 250 | 300 | 350 | 450 | 500 | ||
| water resistance | 80% | 80% | 80% | 80% | 80% | 80% | ||
| moisture content | 2.50% | 2.50% | 2.50% | 2.50% | 2.50% | 2.50% | ||
| horizontal mesh density(lines/100mm) | 10 | 15 | 25 | 36 | 50 | 72 | ||
| longitudinal mesh density(lines/100mm) | 19 | 27 | 37 | 40 | 50 | 80 | ||
We can produce all kinds of product according to customer's requirement, include mesh type, weight, length, packing and others.
