Heavy Duty Rubber Bridge Expansion Joint

Name: Heavy Duty Rubber Bridge Expansion Joint
Brand: HUA YUAN
Price: USD $3.6 - 200.3 / Piece

FOB Price

USD $3.6 - $200.3 / Piece

5 Pieces(Min.Order)

Product Details

Place of Origin:

Henan, China

Brand Name:

HUA YUAN

Model Number:

JGD

Heavy Duty Rubber Bridge Expansion Joint:

size

Nominal diameter (DN)		length	Flange thickness (mm)	Quatity of bolt n	Bolt hole diameter (mm)	Diameter of the central ring of the bolt (mm)	Axial displacement (mm)		Horizontal displacement (mm)	Deflexion angle (a1+a2)°
mm	inch	length	Flange thickness (mm)	Quatity of bolt n	Bolt hole diameter (mm)	Diameter of the central ring of the bolt (mm)	extension	compension	Horizontal displacement (mm)	Deflexion angle (a1+a2)°
150	6	180	16	8	23	240	12	20	14	15°
200	8	210	16	8	23	295	16	25	22	15°
250	10	230	17	12	23	350	16	25	22	15°
300	12	245	18	12	23	400	16	25	22	15°
350	14	255	18	16	23	460	16	25	22	15°
400	16	255	20	16	25	515	16	25	22	15°
450	18	255	20	20	25	565	16	25	22	15°
500	20	255	21	20	25	620	16	25	22	15°
600	24	260	24	20	30	725	16	25	22	15°
700	28	320	24	24	25	840	16	25	22	15°
800	32	340	25	24	30	950	16	25	22	15°
900	36	370	28	24	30	1050	16	25	22	15°
1000	40	400	29	28	30	1160	18	26	24	15°
1200	48	420	32	32	34	1380	18	26	24	15°
1400	56	450	30	36	34	1560	20	28	26	15°
1500	60	500	30	36	34	1660	20	28	26	15°
1600	64	500	30	40	34	1760	25	35	30	10°
1800	72	500	36	44	41	1970	25	35	30	10°
2000	80	550	36	48	48	2180	25	35	30	10°
2200	88	400	40	52	48	2390	25	35	30	10°
2400	96	610	41	56	48	2600	25	35	30	10°
2600	104	650	42	60	54	2810	25	35	30	10°
2800	112	680	45	64	54	3020	25	35	30	10°

The drawing of Heavy Duty Rubber Bridge Expansion Joint:

The process of packaging Heavy Duty Rubber Bridge Expansion Joint:

More information of Heavy Duty Rubber Bridge Expansion Joint pls keep in touch with me:

Gongyi Huayuan Water Supply Equipment Co., Ltd.: Contact nameAlan zhao; Phone86-0371-64011868; AddressXicun, Xicun Town
