CFP series variable frequency power supply
Product Name |
Variable Frequency Power Supply |
||
Model |
CFP33006 |
||
Power |
6KVA |
||
Mode |
IGBT/SPWM Modulation |
||
|
Input
|
Voltage |
3Φ4W+G 380V±15% |
|
Frequency |
40-70HZ |
||
|
Output
|
Wave |
Sine Wave
|
|
Voltage |
High:1Φ2W+G 0-300V |
Low:1Φ2W+G 0-150V |
|
|
current
|
High: 9A |
Low: 18A |
|
Frequency |
50HZ,60HZ Fixed,43HZ-73HZ Adjustable |
||
Frequency accuracy |
≤0.1% |
||
Response time (Input) |
2mS |
||
voltage supplv stability |
≤1% |
||
Load voltage stability |
≤1% |
||
Total harmonic distortion |
≤2%(Linear load) |
||
|
Display diagnostic system
|
Data display |
Voltage, current, frequency, power
|
|
Data analys |
Voltage 0.1V; Current 0.1A; Power 0.1KW |
||
|
Fault diagnosis &display
|
Overload short circuit,IGBT Module,Fuse,High temperature |
||
Screen |
LCD(128*64) |
||
|
Cooling
|
Forced fan
|
||
|
Working Conditions
|
Ambient temperature-10~45℃,Relative humidity0~90% |
||
|
Size (width * depth * high)
|
About 350*650*630mm |
||
|
weight
|
About 65kg |
||
u Product warranty 18 months,life-long maintenance (except abnormal use)
u Goods to the user side, the company in accordance with the specific circumstances of the project, can provide commissioning services, to ensure the normal operation of the equipment as scheduled.
u Conduct occasional telephone and on-site visits, timely understanding of the operation of the equipment, to solve the problem for the user.
u 24 hours service hotline:400 880 1168
IT :Quanta Computer, Foxconn, Maintek Computer, HuaLu Group.
Air conditioning industry : Haier, Gree, ChunLan, Midea, Daikin, Hitachi.
Laser machine Machine tool :Harding, DMG, MAZAK, OR, Jiayou, Daewoo, Trumpf, Bystronic, Mitsubishi, Farley, laserlab, Rofin.
Aerospace Industry :No.3 Institution of CASIC, No.8 Institution of CASIC, Shanghai Aerospace Bureau, No.64 Instition of CASIC, No.610 Instition of CASIC.
Shipbuilding Industry: No704&708 Institute of CSIS. No.1 Machinery Company Kunming Shipbuilding Equipment CO.,Ltd.
Automotive Industry:SAIC, CHERY, BYD, DENSO(China), DENSO(Nansha Guangzhou).
Communication Industry: USA MTN, CHINA TELECOM, CHINA MOBILE, HUAWEI, ZTE.
Scientific Research Institutions: Fudan University, Tongji University, HUST, XMU, LZU.
Medical Industry: HITACHI, SIEMENS, PHILIPS, TOSHIBA, GE ,NEUSOFT.
Steel Industry:Baosteel, HBIS Group, JISCO, Shagang, WISCO.
Export:Japan, Korea, Singapore, Taiwan, Vietnam, Russia, Pakistan, Cuba, India, Nigeria, South Africa.
