Konica 512 14pl Printers

Negotiable MOQ: 1 Unit (Price negotiable depending on order volume and customization)

Key Specifications

Condition:

New

Plate Type:

Other

Place of Origin:

Shanghai, China

Shanghai Color World Industrial Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

China

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Plate Type Other

Place of Origin Shanghai, China

Usage Other

Specifications

1. Konica heads printer, 1440 DPI;
2. Print head: Konica 512 14 pl, 42 pl
3. Printing width: 3.2m
4. Rip software: Maintop

Technical data of Konica 512/42 PL and 14 PL printers

Model			3204K	3206K	3208K	3212K
Konica 512-42PL/14PL Print Head quantity			4	6	8	12
Printing Speed (m2/hour) (42PL/14PL)	2 pass		50/42	50/42	108/90	168/140
	3 pass		44/37	44/37	86/72	144/120
	4 pass		34/28	34/28	60/50	108/90
Ink	Color		4	6	4	4/6
	Type		Solvent or Eco solvent base, CMYK( Lc, Lm optional)
	Supply		Systematic auto continuous ink supply
Printing Resolution			240dpi/360dpi/720dpi/1440dpi
Adjustable Print head Height			2-4mm
Printing Width			1.8m/2.5m/3.3m
Printing material			Frontlit,Backlit,Blockout,Mesh, one-way vision, Canvas,Paper,Fabrics,PVC,Self-Adhesive vinyl
Image File Format			Tiff,jpg,psd,PDF,etc.
Cleaning system			Auto pumping,Auto flash
Ink inspection system			Insufficient ink detector
Printing material feeding system			Auto feeding system, weight less than 120kg (take up system is optional))
Interface			PCI card
Rip Software			Maintop
Workstation Operating System			Windows/XP /Vista/7
Workstation Configuration		CPU	Pentium 4 1500MHz or higher
		Memory	512MB or higher
		Free HD	40GB Minimum
Environment		Humidity	40-70% RH
		Temperature	20-30°C
Power Consumption			220V 8A
Packing Size(mm)			4640970940
Gross Weight(KG)			720
