Mobile Hydraulic Truck Mounted Scissor Lifter/man Lift Work Platform
- Qingdao
- T/T
You May Like
-
Truck-mounted Scissor Lift Platform for Fixing Street Light, Hydraulic Lift Platform on Truck
-
Truck-mounted Mobile Aerial Scissor Lift Platform
-
Mounted Boom Scissor Lift Platform/truck Mounted Boom Lift
-
Jinan High Efficiency Vehicle Mounted Hydraulic Ladder
-
Good Performance Vehicle Mounted Car Lift for Sale
-
China Realiable Vehicle Mounted Hydraulic Car Lift
Product Details
| Place of Origin | Shandong, China | Brand Name | Jinchuan | |
| Model Number | SJGC0.5-3.5 | Lift Mechanism | Scissor Lift | |
| Lift Drive / Actuation | Electric Motor | Power | 3.0KW/380V | |
| Rated Loading Capacity | 500kg | Min. Lifting Height | 450mm | |
| Max. Lifting Height | 3500mm | Table Size | 1600*900mm | |
| Overall Dimensions | 1600*900*450mm | Weight | 1200kg | |
| Certification | CE ISO9001 | Warranty | 12 Months | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
mounted boom lift
This machine can be customized according to your requirement:table size,lifting height,load
Products introduction:
1. Material: mesa mesa use non-skid insulation board
2. The main body framework: the special high strength rectangular pipe 100 mm * 50 mm (jinan)
3. Pin: already do conditioning treatment, greatly improving the service life of the platform
4. Oil cylinder: the fine grinding of hydraulic oil cylinder, cylinder diameter 85 mm * 1, the stability of platform in the form of inclined top further improve (hebei building)
5. The hydraulic tubing: the rubber hose with high pressure double network (xugong production)
6. Power supply: the sino-german pumping station 3.0 KW / 380 v (anshan),
7. 32 # hydraulic oil: the anti-wear hydraulic oil (sinopec Great Wall brand)
8. Sealing ring: adopt Japan wall card,
9. The control mode: up and down for electric control (chint electric or delixi electric)
10. Lifting speed: 4, 8 m/min, and throttle speed is adjustable
Products Photoes:
