hydraulic stationary scissor elevator
Product name:
Stationary hydraulic cargo lift is a specialized hydraulic lift platform designed for the cargo transfer between the heights of buildings.It is mainly used for the vertical cargo conveyance between different heights in workshops,warehouses and all kinds of layer structures,as well as the autombile lifting in the multio-level parking lots and underground multi-level parking lots.The hydraulic system of the proudct is equipped with anti-falling,over-load safety protection device.Every floor of the building and every platform of the lifts may have operation buttons to provide multi-point contrlol function.
Application:
It is droved by the electric and hydraulic systerm,,the lift platform is lifted up and drops down along the track;it is installed in the pit or the ground floor to convey the goods from one floor to another and convey the goods from one working level to another.The control panels are available at the designated floors and on the lift platforms.
Safe set:
1.Stationary hydraulic lift table is equipped with overload protection devices.
2.The lift platform could stop at the accurate loaction point if the supply power stop suddenly.
Models and parameters:
Model # |
Load Capacity |
Table Size |
Lifting Height |
No-working |
Overall Dimensions |
Motor Power |
SJG0.8-3.5 |
0.8T |
1.8×1.2M |
3.5M |
800MM |
1.8×1.2×0.80M |
2.2KW/380V |
SJG2-3.5 |
2T |
1.8×1.2M |
3.5M |
680MM |
1.8×1.2×0.68M |
3KW/380V |
SJG2-0.5 |
2T |
1.8×1.6M |
0.5M |
440MM |
1.8×1.6×0.44M |
2.2KW/380V |
SJG1-6 |
1T |
1.9×1.1M |
6.0M |
1100MM |
1.9×1.1×1.10M |
3KW/380V |
SJG2-6 |
2T |
2.0×1.3M |
6.0M |
1200MM |
2.0×1.3×1.20M |
4KW/380V |
SJG1.5-0.8 |
1.5T |
2.0×1.5M |
0.8M |
500MM |
2.0×1.5×0.50M |
3KW/380V |
SJG1-4.3 |
1T |
2.0×1.8M |
4.3M |
800MM |
2.0×1.8×0.80M |
4KW/380V |
SJG2-6 |
2T |
2.0×2.0M |
6.0M |
1030MM |
2.0×2.0×1.03M |
4KW/380V |
SJG3-2.4 |
3T |
2.0×2.0M |
2.4M |
630MM |
2.0×2.0×0.63M |
2.2KW/380V |
SJG3-2.4 |
3T |
2.0×2.0M |
2.4M |
660MM |
2.0×2.0×0.66M |
4KW/380V |
SJG2-5 |
2T |
2.1×1.2M |
5.0M |
870MM |
2.1×1.2×0.87M |
4KW/380V |
SJG1-4.5 |
1T |
2.1×1.5M |
4.5M |
800MM |
2.1×1.5×0.80M |
3KW/380V |
SJG5-6.5 |
5T |
2.2×1.6M |
6.5M |
1280MM |
2.2×1.6×1.28M |
5.5KW/380V |
SJG3-6.5 |
3T |
2.2×1.9M |
6.5M |
1520MM |
2.2×1.9×1.52M |
5.5KW/380V |
SJG1.5-3.8 |
1.5T |
2.2×2.0M |
3.8M |
700MM |
2.2×2.0×0.70M |
4KW/380V |
SJG2-3.8 |
2T |
2.2×2.0M |
3.8M |
830MM |
2.2×2.0×0.83M |
4KW/380V |
SJG2-5 |
2T |
2.3×1.4M |
5.0M |
870MM |
2.3×1.4×0.87M |
4KW/380V |
SJG2-5.15 |
2T |
2.3×1.4M |
5.1M |
870MM |
2.3×1.4×0.87M |
4KW/380V |
SJG2-1.3 |
2T |
2.3×2.0M |
1.3M |
400MM |
2.3×2.0×0.40M |
2.2KW/380V |
Company and conact information:
Jinan jinchuan hydraulic machinery co., LTD. is a design, development, production, sales in the integration of enterprise, specializing in the production of elevator, lifting platform, such as hydraulic lifting machinery and aerial work platform.The company has sophisticated production equipment, strong technical force and the detection means complete.According to the development trend of similar products at home and abroad, and taking market demand as the guide, the development of many varieties and specifications of products, and according to the customer request custom make. Products with novel design, the operation is simple, steady lifting, reasonable structure, convenient maintenance etc.Widely used in industrial and mining enterprises, factory premises warehouse, station wharf, warehousing logistics, property management, maintenance clean and so on the many kinds of industry and the place.
The company take "the good faith for this, science and technology and innovation" for the purpose of "quality first, customer first" for the concept, to serve the new and old customers. The company by the high quality product quality and perfect after-sale service, we warmly welcome all friends to come to visit, study, business negotiations.
TlEL:86-0531-84231376
FAX:86-0531-84233276
MO:86-18668910306
Skype:jinchuanlift
ADD:Taixing Rd.,Jibei Development Zone,Jiyang County,Jinan,Shandong,China
Welcome to visit.
