Specifications
Fixed UHF Four Channel ReaderUHF RFID Reader
Fixed RFID Reader
Large reading range with 4 antennas
High class UHF Reader
Features
1)Special Anti collision algorithm, high efficient of multi-tag identify capability;
2)Four separate transmit/receive antenna to make more wide of area in the application;
3)Compatible ISO18000-6B and ISO18000-6C(EPC-GEN2) protocol standard;
4)Read/Write tag capability: read >12m,write is 60% of read reading(depend on different tag)
5) Reader support multi tag identify,single tag read,tag write,lock,and Kill tag etc.
Specification | |
Protocol |
ISO18000-6B,ISO18000-6C(EPC GEN2) |
Frequency |
Standard: ISM 902~928MHz and ISM 865~868MHz optional, others customized |
Work mode |
FHSS |
RF power |
0~30dBm,adjustable by the software |
Communication |
Standard RS232, RJ45(TCP/IP), RS485 |
Output |
4 sets of OUTPORT(user can set output high and low level) |
Read range |
Depend on the antenna outside, if connected with 12dBi antenna can reach 12m |
Read indicator |
Buzzer and LED |
Antenna |
Can connect with four antenna outside and with TNC connector |
Power |
DC+9V(with AC/DC power adapter) |
Size |
310mm×210mm×40mm |
Weight |
2 Kg |
Work temp. |
-20°C~+80°C |
Certificate |
FCC CE CCC |
Application:
1. Logistics and warehouse Management: Goods flow, warehouse management, and the flowing management of mail, parcel, luggage.
2. Productive lines Management: Production process fixed Identify
3. Product counterfeit-proof inspection: Using memory’s write-protect functions inside tags, and identifying with true-false of products
4. Other fields: Used widely in club management, library, student’s school, consumption management, time management, dinner management, pool management
