High Quality Waste Tyre Recycling of Tyre Shredder Machine

Motor power

Blade speed

Adaptation tires

Production capacity

Dimensions

Weight

3KW

15R/MIN

650--1200

30article/h

1150*850*1200

0.5T

Motor power

Processing efficiency

Processing diameter

Discharge Size

equipment size

Equipment weight

4KW

20bars/h

<1200

25-55

1230*650*1580

0.8T

Motor

power

Processing efficiency

Discharge Size

equipment size

Equipment weight

7.5KW

0.8-1T/H

35*35

780*550*1210

0.8T

Motor

power

Blade  speed

Adaptation tires

Production capacity

Weight

Dimensions

11KW

18r/min

650-1200

1-2bars/min

1500KG

1700*1200*1300

Host

Equipment

Quantity

Equipment Description and Function

Rubber crusher

1

The waste tire rubber and miscellaneous plastic pieces were breaking milling cycle

Equipment

Ring cutter

1

Will tire side and tire top joint use a knife to slice; Make the side of the tire and tire top complete separation

Strips cutter

1

Will be cut into strips the tire sidewall, tire I circle reserved

Rim cutter

1

The tires will be cut into strips cut into 3.5 cm square block

Big Shaker

1

The powder for the first time separation (8 - 10 mesh)

Small shaker

1

The powder for the second time separation (20-30mesh)

Large conveyor

1

It is used for transportation does not meet the requirements of mesh powder to return the host to continue breaking

Magnetic separation unit

1

The powder was extracted in the separation of the metal wire

Fiber separator.

1

The powder was extracted in the wool fiber

Steel separator

1

will tire of crude steel mouth ring and rubber parts completely separated

Remarks

Above unit is in the process of tires used to crush the machine
