Specifications
125khz module1.support EM4200 or TK4100 Chip card
2.the interface is RS 232,TTL,WG26
3.high sensitivity and stable
RFID 125khz module
1.support EM4200 or TK4100 Chip card
2.the interface is RS 232,TTL,WG26
3.high sensitivity and stable
Product Description
M6630 is a RFID module supporting 125 KHz RFID cards. The module, which adopts advanced RFID circuits, embedded microcontroller design, and efficient decoding algorithm, receives the data of EM4100 cards, compatible ID cards. It is used for access control, time attendance, collecting fees, and guard against theft, and so on.
Main Parameters
Model |
M6630-W/ M6630-S |
Dimensions |
39 mm×19mm×9mm |
Operating Temp |
0°C to +50°C |
Interface |
Weigand26/RS232 (option) |
Protocols |
ISO11784, ISO11785 |
Cards Supported |
EM4100 cards, compatible ID cards |
Read Range |
3-10cm (Depend on the reader and cards) |
Power Supply |
5V, external power supply |
SDMW Introduction
As an excellent RFID manufacturer in China, SDMW specializes at RFID handheld readers, RFID fixed readers, RFID antennas and RFID solutions for assets management, logistic management, personnel location management, production line management, high-value commodity anti-counterfeiting etc…
With 15 years RFID experience, SDMW has formed a professional technical team, and cooperate with many famous corporations both home and aboard. Our classic solutions include South Korean Marathon timing system, Kazakhstan payment system, USA warehouse management system etc. SDMW has resellers and distributor in over 55 countries. It takes 80% of domestic market on RFID readers.
We are sure that our experience on serving these tycoons will help us to do better than ever in future!
