Specifications
Magnetic Swipe Card Writer & Reader1)Interface : RS232,USB
2)Track : 1,2 or 2,3 or 1/2/3
Magnetic Swipe Card Writer & Reader
Why do you choose us?
&15 years experience in RFID field
&Experienced in RFID software and hardware
&Timely delivery, competitive price and free sample for test
1. Brief Description:
1)Interface : RS232,USB
2)Track : 1,2 or 2,3 or 1/2/3
2.Performance Characteristics:
Main Parameters
Model | MW4XX |
Protocols | ISO7811-7815 |
Decode Mode | F2F (FM) |
Swipe Speed | 10cm/s to 120cm/s |
Interface | Keyboard port/RS232/USB |
Magnetic Head Life | ≥50,000times |
Power Supply | DC 5V±5% |
Operating Temp | 0°C to +45°C |
Humidity | 10%RH to 90%RH |
Ordering Information
Model | Parameters |
MW401 (R)(U) | Track 1, keyboard wedge output |
MW402 (R)(U) | Track 2, keyboard wedge output |
MW403 (R)(U) | Track 3, keyboard wedge output |
MW412 (R)(U) | Track1,2, keyboard wedge output |
MW423 (R)(U) | Track 2,3, keyboard wedge output |
MW433 (R)(U) | Track 1,2, 3, keyboard wedge output |
Note:
R stands for RS232 output, for example, MW401R: track 1, RS232 output.
U stands for USB output, for example, MW401U: track 1, USB output.
3. Contact Detail:
Address | Yinhe Building, 2008 Xinluo str. High-tech District, Jinan 250101 Shandong Province, China |
Office | 0086-531-66955507 |
Skype | H.rfidtag10 |
4.Product detail picture:
