Programmable Pos Terminal GPRS,GPS Industrial Design

Name: Programmable Pos Terminal GPRS,GPS Industrial Design
Brand: MingWah
SKU: 102794207
Availability: InStock

US$ 600 - 10,000 MOQ: 1 Piece

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

MingWah

Model Number:

MS-7000

Shandong Mingwah Aohan Smart Tech Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Jinan or Qingdao

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name MingWah

Model Number MS-7000

Specifications

Programmable pos terminal
#External antenna for camera protection
#Exqusite industrial design portable pos
#Fast delivery

Programmable pos terminal GPRS,GPS industrial design

Features

Ø Industrial design, well performance in all kinds of environment

Ø Barcode scanner,1D/2D barcode reading

Ø RFID reader UHF

Ø Wireless/communication: GPRS/Zigbee/Wifi/433M/Bluetooth

Ø IP64 protection water proof

Ø Human Engineering design

Ø SD card support

Ø Anti-hit: Base on the design of anti-hit. It is acceptable drop from 1.5 m height to concrete ground

For more detailed information pls contact Ms. Ada~ or visit our website

Picture for your reference~

Physical Parameters
Dimension	186.57548mm(4,000mAH battery)
Weight	500g
Screen	Transmission-type 3.2 inch QVGA (240*320 pixel) 65K quality TFT-LCD,LED backlight
Touch Panel	vitreous touch screen in strong
Back light	LED backlight
Battery	Recharge polymer battery (3.7V 4,000mAH)
CARD	SIM Micro SD(TF) CARD
Input	Stylus Pen, multiple input
Audio	Loud speaker 0.5W
Development
OS	Microsoft Windows CE 6.0
Language	C++,C#,.NET
Develop tool	Visual Studio 2005/2008 Provide Software Development Kit(SDK)
Performance Parameters
CPU	Samsung ARM920T@533MHz
Memory	128MB RAM/1GB Flash
Interface	USB
Keypad	31 silicon keypad
Work Environment
Work Temp	-20°C to 50°C
Store Temp	-25°C to 70°C
Humidity	5%RH--95%RH
Anti hit	Anti-hit from dropping from 1.5 m height to concrete ground
Protection rate	IP64
Wireless Communication
GPRS	Support GPRS(900,1800MHz)
WIFI	IEEE802.11b( speed 11M/s) IEEE802.11g(speed 5.4M/s)
Data collector: 13.56Mhz ISO14443 Type A
RFID	M1 card support Work Frequency: 13.56Mhz
Protocol	ISO14443 Type A
Read range	3-10 cm
Interface	USB2.0 RS-232(option)
Accessories
Data wire	1 pcs, be used for recharge
Pocket	1
Protable recharger	1
Stylus Pen	1
Accessories for option: Micro SD(TF)card Recharge foundation Printer with blue tooth connectivity
