Home > Manufacturing & Processing Machinery > Lifting Equipment > Lifting Table > 6m Small Mobile Aluminum Hydraulic Lift Platform
6m Small Mobile Aluminum Hydraulic Lift Platform
US$ 1,000 - 10,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Shandong, China
Brand Name:
Jinchuan
Model Number:
SJYL
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
9meter Small Lift Mobile Portable Aluminum Work PlatformUS$ 1,000 - 10,000MOQ: 1 Set -
V100-200kg Small Lift Platform (single Mast Platform) Aluminum PlatformUS$ 1,000 - 10,000MOQ: 1 Set
-
Self-propelled Aluminum Alloy Lifting PlatformUS$ 1,000 - 10,000MOQ: 1 Set
-
New Self Propelled Elevating/liftUS$ 7,000 - 10,000MOQ: 1 Set
-
Self Propelled Lift Multi Purpose ElevateUS$ 7,000 - 10,000MOQ: 1 Set
Place of Origin
Shandong, China
Brand Name
Jinchuan
Model Number
SJYL
Lift Mechanism
Telescoping Lift
Lift Drive / Actuation
Hydraulic
Power
2.0kw
Rated Loading Capacity
200kg
Min. Lifting Height
1.8m
Max. Lifting Height
12m
Table Size
1.5*0.6m
Overall Dimensions
According to customer's requirements
Weight
200kg
Warranty
one year
Specifications
1.excellent stability2.smart operation
3.easy to implement
4.large platform area
Introduction:
TMAP series mobile aluminium working platform- Single mast
1)Can Bus Technology
2)Protectional control
3)Safety brackets
4)Low voltage alarm
5)Emergency down button
6)Tilt protection
7)Controller temperature protection
8)Over loading limited
Parameter:
| Model | TMAP 6-1000 | TMAP 8-1000 | TMAP 10-1000 | |
| Lift Rated Capacity | kg | 150 | 125 | 125 |
| Working Height | mm | 8000 | 10000 | 12000 |
| Platform Height | mm | 6000 | 8000 | 10000 |
| Overall Length | mm | 1420 | ||
| Overall Width | mm | 820 | ||
| Overall Height | mm | 1920 | 2080 | 2150 |
| Overall Net Weight | kg | 415(AC)/450(DC) | 450(AC)/485(DC) | 490(AC)/525(DC) |
| Ground Clearance | mm | 60 | ||
| Platform Size | mm | 630x650 | ||
| Wheel Base | mm | 1110 | ||
| Lifting Motor(AC) | V/KW | 110-230/0.75 | ||
| Lifting Motor(DC) | V/KW | 12/1.5 | ||
| Max Lifting speed (up/down) | Sec | 38/35 | 44/38 | 46/40 |
| Tyre Size (Front/Back) | inch/mm | 6/Ø180x50 | ||
| Battery | V/Ah | 2x12/150 | ||
| Integrated Charger | V/A | 12/15 | ||
similar production show
24hours 365days service for you
Send Inquiry to This Supplier
* Email
Want the best price?
Post an RFQ now!
Business Type
Manufacturer
Year Established
2009
Factory Size
1,000-3,000 square meters
Total Employees
201 - 300 People
