Specifications
er14335 battery1) Nominal voltage 3.6V
2) Nominal capacity 1600mAh(0.7mA / 2.0V)
3) Discharge end-voltage 2.0V
ER14335M lead wire, molex plug, provide higher power work in toll station.
| model no. | Norminal Capacity | Norminal Voltage | Max.Operating current(mAh) | Norminal Discharge current | Cut off voltage | Max.Dimensions(mm) | Weight | Operating temperature | |||
| GB | IEC | (mAh) | (V) | Continuous | Pulse | (mA) | (V) | Diameter | Hight | (g) | (C) |
| ER14335M | 2/3AA | 1300 | 3.6 | 100 | 500 | 1 | 2.0 | 14.5 | 33.5 | 13 | -40~+85 |
3.6V 2/3AA ER14335M Lithium Thionyl Chloride Battery
Feature:
1. stainless steel cans
2. hermetic glass-to-metal sealing
3. non-flammable electrolyte
4. shelf life can last than 15 years
5. like working in automatic toll station
6. compiant for IEC safety standard, CE, UL, UN approved
Specification:
1) Nominal voltage 3.6V
2) Nominal capacity 1600mAh(0.7mA / 2.0V)
3) Discharge end-voltage 2.0V
4) Operating voltage 3.3V(330Ω, in 5s)
5) Max constant discharge current 50mA
6) Max. pulse current 100mA
7) Ambient temperature range -55+85C
8) Yearly self-discharge ≤ 1%
9) Highest energy battery (500wh/kg,1000wh/L)
10) Stable discharge voltage
Applications:
Automatic Toll Station, CMOS memory chips for PC,office automation devices,remote data logging and data acquisition systems,medical instrument,water or gas gauges,security and alarm systems. Pulse/event-counters , wireless/cordless communications et
