Cheap Good Scissor Lift Lift Mechanism and Hydraulic Lift Drive / Actuation Scissor Lift Table
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Shandong, China
Brand Name:
jinchuan
Model Number:
SJY0.3-10
Payment & Shipping
Payment Methods:
Port of Shipment:
qingdao
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Cheap Small Portable Scissor Lift Mechanism Light Weight Scissor Lift for Hot SalesNegotiableMOQ: 1 Set -
Towable Electric Hydraulic Movable Scissor Lift Lifting PlatformNegotiableMOQ: 1 Set
-
SJY0.5-14 Hydraulic Towable Mobile Scissor Lift Platform/scissor LifterNegotiableMOQ: 1 Set
-
Hydraulic Mobile Lift Platform/battery Powered Scissor Lift Platform/ Goods LiftNegotiableMOQ: 1 Set
-
Small Scissor Lift Hydraulic Mobile Scissor Lift Four-wheels Hydraulic Mobile Scissor LiftNegotiableMOQ: 1 Set
Place of Origin
Shandong, China
Brand Name
jinchuan
Model Number
SJY0.3-10
Lift Mechanism
Scissor Lift
Lift Drive / Actuation
Hydraulic
Power
2.2kw
Rated Loading Capacity
300kg
Min. Lifting Height
1530mm
Max. Lifting Height
10000mm
Table Size
2100*1200mm
Overall Dimensions
2600*1500*1530mm
Weight
1600kg
Certification
CE ISO9001
Warranty
12months
Movable scissor lift plaform for 10m aerial working Specification
Our lifting Machinery with high working capacity, most spacious platforms for several people to work on, easily moved, high strength steel structures, smoothly lifting up and dropping down, easily operated few faults.
Moving method
4 wheel mobile or 2 wheel towable, tires are optional, it could be pneumatic rubber tires, solid rubber tires or polyurethane tires.
Power sources
Local power available at the working sites(110V, 220V, 380V, 415V) Working heights: Ranging from 4m, 6m, 8m, 10m, 12m,14m
Application
It is widely used for the equipments installations and maintenance at the following places like construction sites
Workshops, warehouse, granary, bus/railway stations, hotels, airports, gas station and aerial pipeline.
We can design good as customers' requirements! You just tell us your demand:lifting height,load,and you local power
Specifications
Model number :SJY0.3-10
Rated lifting capacity kg:300
Maximum working heightmm:1530mm
Maximum platform heightmm:10000mm
Overall lengthmm:2600mm
Overall widthmm:1500mm
Overall heightmm:1530mm
Platform sizemm:2100*1200mm
Ground clearance::60mm
Wheelbase:990mm
Minimum turn radiusmm1200
Drive motorv/kw2x24/0.4
Lifting motorv/kw24/0.8
Travel speed(Platform stowed)km/h4
Travel speed(Platform elevated)km/h0.8
Rising/lowering speedsec20/30
Batteryv/ah2x12/80
Chargerv/ah24/12
Maximum gradeability%10-15
Maximum angle/2°
Drive wheelmm230x80
Front wheel 6
Overall weight kg 490 of movable scissor lift plaform for 10m aerial working.
Our lifting Machinery with high working capacity, most spacious platforms for several people to work on, easily moved, high strength steel structures, smoothly lifting up and dropping down, easily operated few faults.
Moving method
4 wheel mobile or 2 wheel towable, tires are optional, it could be pneumatic rubber tires, solid rubber tires or polyurethane tires.
Power sources
Local power available at the working sites(110V, 220V, 380V, 415V) Working heights: Ranging from 4m, 6m, 8m, 10m, 12m,14m
Application
It is widely used for the equipments installations and maintenance at the following places like construction sites
Workshops, warehouse, granary, bus/railway stations, hotels, airports, gas station and aerial pipeline.
We can design good as customers' requirements! You just tell us your demand:lifting height,load,and you local power
Specifications
Model number :SJY0.3-10
Rated lifting capacity kg:300
Maximum working heightmm:1530mm
Maximum platform heightmm:10000mm
Overall lengthmm:2600mm
Overall widthmm:1500mm
Overall heightmm:1530mm
Platform sizemm:2100*1200mm
Ground clearance::60mm
Wheelbase:990mm
Minimum turn radiusmm1200
Drive motorv/kw2x24/0.4
Lifting motorv/kw24/0.8
Travel speed(Platform stowed)km/h4
Travel speed(Platform elevated)km/h0.8
Rising/lowering speedsec20/30
Batteryv/ah2x12/80
Chargerv/ah24/12
Maximum gradeability%10-15
Maximum angle/2°
Drive wheelmm230x80
Front wheel 6
Overall weight kg 490 of movable scissor lift plaform for 10m aerial working.
| QC | Strict QC CE/ISO/SGS |
| Packing | Wooden Cases |
| Delivery | In time |
