mobile lift according to your requirement/mobile scissor lift platform
This kind of working platform is elevated by the hydraulic system, Easy to control and could be moved easyly,common tool, widely used in workshop. the elevating height could reach 14000mm.
Patameter:
| Mobile scissor lift platform | model | lifting weight(kg) | table size(mm) | lifting height(m) | overall dimension(mm) | power(kw) | mahine weight(kg) |
| SJY0.3-4 | 300 | 1600*900 | 4 | 1700*1150*1100 | 2.2 | 400 | |
| SJY0.3-6 | 300 | 1600*900 | 6 | 1700*1150*1290 | 2.2 | 650 | |
| SJY0.5-6 | 500 | 1600*900 | 6 | 1700*1150*1290 | 2.2 | 700 | |
| SJY0.3-8 | 300 | 1700*900 | 8 | 2100*1150*1400 | 2.2 | 720 | |
| SJY0.5-8 | 500 | 1700*900 | 8 | 2100*1150*1400 | 2.2 | 750 | |
| SJY0.5-8big | 500 | 1800*1200 | 8 | 2200*1500*1400 | 2.2 | 1000 | |
| SJY0.3-9 | 300 | 1800*1200 | 9 | 2200*1500*1450 | 2.2 | 850 | |
| SJY0.3-10 | 300 | 2100*1200 | 10 | 2600*1500*1530 | 2.2 | 1500 | |
| SJY0.5-10 | 500 | 2100*1200 | 10 | 2600*1500*1530 | 2.2 | 1600 | |
| SJY1.0-10 | 1000 | 2200*1500 | 10 | 2650*1900*1740 | 3.0 | 2200 | |
| SJY0.3-11 | 300 | 2100*1200 | 11 | 2600*1500*1650 | 2.2 | 1650 | |
| SJY0.3-12 | 300 | 2530*1500 | 12 | 2950*1950*1740 | 3.0 | 2580 | |
| SJY0.5-12 | 500 | 2550*1500 | 12 | 3000*1950*1850 | 3.0 | 2700 | |
| SJY1.0-12 | 1000 | 2600*1500 | 12 | 3200*2000*2130 | 3.0 | 3400 | |
| SJY0.3-14 | 300 | 2750*1500 | 14 | 3250*1950*1970 | 3.0 | 2900 | |
| SJY0.5-14 | 500 | 2980*1500 | 14 | 3300*2000*1970 | 3.0 | 3000 | |
| SJY1.0-14 | 1000 | 3000*1600 | 14 | 3400*2200*2300 | 3.0 | 3600 | |
| SJY0.3-16 | 300 | 3000*1500 | 16 | 3600*2000*2300 | 3.0 | 3650 | |
| SJY0.5-16 | 500 | 3200*1500 | 16 | 3600*2000*2300 | 3.0 | 3700 | |
| SJY0.3-18 | 300 | 3200*1600 | 18 | 3700*2100*2500 | 3.0 | 3900 |
Details:
This kind lift platform has several models on different standards.
Lifting height: 4m, 6m, 8m, 10m and 18m etc.
Loading capacity: 100kg, 200kg, 300kg and 2000kg etc.
Supplying capacity:
We have regular model of lift kept in our warehouse, they can be delivered as soon as the order comes. Or we manufacture the machine according to the order that the customer gives, with special design.
Power driven:
The usual power supply is external connection electricity variety of 220v, 240v, 380v, 400v. and they also can be equipped with handle control, in case the power is not available that the lift can work.
Packing & shipping:
We always have our lift platforms we sold out packed with warp film inner and plywood case outer, and deliver them by ship.
About Jinchuan company:
Jinan Jinchuan company, located at the cross between Longhai Road and Taixing Road in Jinan jibei economic development zone, is a professional maunfacturer of developing and producing different models lift platforms and dock ramps. We have faith and enough experience in making the lift platform you want, if you have interest in our lift platform, you can contact us or come to visit our factory!
Factory room:
Certificate:
Customers:
1. What’s the information should I provide when inquiry?
More details or drawings, more better.
A: Lift capacity
B: span
C: lift height
D: power source
Or other specials you give us will be more appreciated.
2. How many operating methods for my selection?
Standard operating methods:
A: pendent controller with push buttons.
B: remote control with push buttons
C: cabin(space capsule seat) control with joystick.
Choose any type as you like.
3. Can this type work in hazardous environment?
Sure! Can customize for you, acid proof or explosion proof, no problem for that.
4. How long is your warranty?
Our warranty is 15 months after received the goods.
5. Can you provide the serious lifting tools?
Sure, we can provide any lift tools such as lifting sling belt, lift clamp, grab, magnet or other specials as your requirement!
6. Usage period
About 30 years under common use.
7. How can we install the crane?
Our senior engineer can be your side to do the installation guide service and traning. Moreover, our best sales can visit your country.
8. Safety device
Overload limiter, limit switch (lifting and traveling), interlock protection device, Buffer, overhaul cage, rail clear plate, protective, bus bar preventer plate, anti-collision device, main isolating switch, Emergency stop system, motor overload protection, and so on.
If you like our lift platform or you have any questions, pls feel free to ask me, I will answer you as soon as possible. You can contact me by Skype or Email, other methods.
Skype: jinchuanlift
Email: jinchuanlift02/at/
