Home > Products > mobile scissor lift platform > 1.35~12m, 0.3 ton mobile hydraulic lifting /stationary scissor /hydraulic arm lift platform

1.35~12m, 0.3 ton mobile hydraulic lifting /stationary scissor /hydraulic arm lift platform

FOB Price

USD $5,565 - $5,565 / Set

1 Set(Min.Order)

Supply Ability 500 Set / Sets per Month
Port Qingdao/Guangzhou
Payment TermsT/T L/C D/P D/A Credit Card PayPal

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Shandong, China	Brand Name	JINCHUAN
Model Number	SJY0.3-12	Lift Mechanism	Scissor Lift
Lift Drive / Actuation	Hydraulic	Power	3kw
Rated Loading Capacity	300kg	Min. Lifting Height	1350 mm
Max. Lifting Height	12m	Table Size	2530*1500
Overall Dimensions	295029501740	Weight	2580kg
Certification	CE&ISO9001:2000	Warranty	1 year
After-sales Service Provided	Engineers available to service machinery overseas

Product Description

Hydraulic Scissor Lift

Product Description

Scissor lift is the professional high-altitude operation equipment, widely used for the installations maintenance, highworking capacity, most spacious platforms to load several people to work on.

Operate & Power:

A. Standard operating methods:

pendent controller with push buttons

remote control with push buttons

cabin (space capsule seat) control with joystick

B. Electric powered

The usual power supply is external connection electricity variety of 220v, 240v, 380v, 400v

Detail Features

A. Smooth starting and stopping

B. Low noise, commodious cabin and good view

C. Convenient maintenance, excellent exchangeability for parts and components

D. Energy saving,reduce energy consumption

E. Using transducer for travelling or traversing crane to realize step speed or stepless speed change

F. Primer and finishing paint

G. Crane structure:steel box type

Specification:

Model	Work height	Capacity	Table size	Total dismension	Mating power
SJY0.3-4	4 m	300 kg	1600*750 mm²	17009001100 mm³	2.2 kw
SJY0.3-6	6 m	300 kg	1600*750 mm ²	17009001290 mm ³	2.2 kw
SJY0.3-8	8 m	300 kg	1700*900 mm ²	185012001350 mm ³	2.2 kw
SJY0.3-9	9 m	300 kg	1800*1200 mm ²	220015001450 mm ³	2.2 kw
SJY0.3-10	10 m	300 kg	2100*1200 mm ²	260015001530 mm ³	2.2 kw
SJY0.3-11	11 m	300 kg	2100*1200 mm ²	260015001650 mm ³	2.2kw
SJY0.3-12	12 m	300 kg	2530*1500 mm ²	295019501740 mm ³	3.0 kw
SJY0.3-14	14 m	300 kg	2750*1500 mm ²	325019501970 mm ³	3.0 kw
SJY0.3-16	16 m	300 kg	3000*1500 mm ²	360020002300 mm ³	3.0 kw
SJY0.3-18	18 M	300 kg	3200*1600 mm ²	370021002500 mm ³	3.0 kw

Certifications

Our Services

We supply products with customized design by professionals

The English operation instruction will be attached before shipment

The professionals will be sent aboard for installation and instruction at customer's request

The warranty period of the machinery is 12 months
