88 extensions VoIP PBX phone system , IP PBX, FXO/FXS optional
Poduct Function
System TFTP upgrade |
Data backup and restore |
| SIP 2.0 Standard |
| WEB remote interface management |
| Multiple voice codec format(A,U,iLBC,G729 |
| Multiple voice codec format |
| 100 IP extension account |
| 4 Traditional voice concurrent channel |
| 20 IP plarform concurrent calls |
| IP voice calls bypass |
| IP extension account,IP trunking support SIP type |
| Flexible networking |
| DDNS( Dynamic Domain Name Service) |
| IP call extension acoount level limit |
Detail descripition
Automatic Operator Service VIP Operator Service
IVR Selection per CPN
Login Authentication & GUIAdministrator account (1)Main Line (3 accounts)Extensions (30 accounts)
Busy Line Indicator
SIP / PSTN Trunking
Extension Calling
Extension RestrictionIntra-Network,
Local, Domestic, and International Calls Direct ,Inward Dialing Emergency
Call Manager/Secretary Functions
Music on Hold
Distinct Ringing
Location Free Extension Dialing
Incoming Call History
Outgoing Call History
Calling Detail Record
Real Time Extension Line Status
Busy/Idle Display Extension/ID Display Presentation Status
Call Transfer
Personal Ring-Back Tones
Call Rejection (Call Cancellation)Selective Call Rejection
Click-to-Dial
Three Way Calling
Phone Book Grouping (User group, FXO group, etc.)
Line Hunt Group (Serial & CircularHunt)
Name/Title Display
Outgoing Line Selection
Hot Line
Custom Dialing PlanLeast Cost Routing
Do Not Disturb
Call Waiting
Call Hold,Hot Line (Instant or Delay)
Speed Dial List (30/Line)
Caller ID Suppression
Outgoing Call BarringCaller ID (Name & Number)
Caller ID on Call Waiting
Specification Parameter
| Size | 430*240*124mm |
| Weight | 3kgs |
| FXx(PSTN) | 4/10 |
| FXO+FXS | 4/88 or 10/72 |
| CDMA/GSM | Optional |
| IP user | 100 |
| IP concurrent | 20 |
IP and Traditional voice concurrent channel | 4 |
| SIP trunk | 9 |
| LAN Port | 1 |
| SIP Protocol | YES |
| Record | Optional |
Power Specification
Power supply voltage: 110VAC or 220 VAC,50/60 Hz
Maximum power consumption: 65W
Operating temperatures: 0°C to 45°C (32°F to 113°F) ,26±5°c for best
Operating humidity: 10% to 95% without condensation
Feature phone: Maximum 100m(2 pairs twisted wire 0.5@)
Single line phone: Maximum 1,000m(1 pair twisted wire 0.5@)
Connect with PC, connecting length:<30m
(1)Source of music:
Input impedance:600Ω
Input audio level:025Vpp-1Vpp
Output impedance:600Ω
(2)Battery backup supply:24VDC/76Ah
Product feature
1) Smooth transition, compatible with tradition and the future
2) The remote call zero cost
3) WIFI mobile together with wired network
4)The number of unique passthrough
5) Comprehensive generalist
Installation drawing
