Specifications
China new product Hotel PBX Intercom For Hotel Intercom4~8 Co Lines 16~64 Exts
Billing system, prepaid
Busy transfer
Hotel Hybrid IP PBX Intercom For Hotel system
Capacity:co.lines-4~10,Exts.-16~88
Weight:9KGS
Size:430*240*124mm
Note:Connect the mainboard EXPCN1 slot or extension of the slots on the board expansion slots (50P)
Can be connected with12 key phones
System programmed and monitored by key phone easily.
Built-in 6 duration Out-Going Message
Built-in Caller ID function for intercom and outside Line number and number can be transferred display again and again.. An incoming calls number can be displayed at 5 extensions at same time.
Economical Code auto-route
Select a CO Line directly without dialing digit “9”.
Day/Night Service manually
Flexible Extension Numbering
255 groups Walking Account Code
Manger/Secretary Call-group
3-party Conference Call
Hot Dialing
Auto call back on busy
Multi-answer Mode
Call Forward
Setting Operator
Extension lock
Call Pick-up
Conversation Time Alarm
Interrupt and disconnect an outside call
Detailed Product Description
| Model | WS824(9)H |
| Photos | |
| Basic Capacity | 4 Cos 16 Exts |
| Max Co Lines | 8 |
| Max Exts | 64 |
| Size(L*W*H)(mm) | 485*300*110 |
| Weight(kg) | 8 |
| Auto-attendant | 1 Road 6 Parts/ 1 Road Expandable |
| Key Phone | 4 |
| Caller ID Display | Y |
| Call Queuing | 1 Group |
| Support Trunk Affiliate | Y |
| Voice Report Number | Y |
| Billing software | Y |
| Managing software | Y |
| Back-up battery interface | Optional |
| Exts flexible numbering | 1-8 leading |
| Auto Day/Night Service | Y |
| Mobile Account | 255 Groups |
| Auto IP economical route | Y |
| Paging | Y |
| Call to Exts when power off | 4 Roads |
| Multi-party Conference | 2 Groups 8 parties |
| Manger-Secretary function | Y |
| Class of Services Restrict | Y |
| Conversation Time Limitation | Y |
| Setting Operator | Y |
| Reversed Polarity inspection | Y |
| Hotline Dialing | Y |
| Special Line for incoming and outgoing call | Y |
| External Music Port | Y |
| Call Cut-Off | Y |
| Extension charge Prepaid | Y |
| Extension Alarm | Y |
| Key Phone dispaly | English/Chinese |
| DISA Co line to Co line | Y |
| Auto Call Back if transfer with no-answer | Y |
| Call Hold Retrieve | Y |
| Do not Disturb | Y |
SPECIFICATION
Power Specification
Power supply voltage: 110VAC or 220 VAC,50/60 Hz
Maximum power consumption: 80W(5A)
Cross-talk attenuation: >70db
Operating temperatures: 0°C to 45°C (32°F to 113°F)
Operating humidity: 10% to 95% without condensation
Feature phone: Maximum 100m(2 pairs twisted wire 0.5@)
Single line phone: Maximum 1,000m(1 pair twisted wire 0.5@)
Connect with PC, connecting length:<30m
(1)Source of music:
Input impedance:600Ω
Input audio level:025Vpp-1Vpp
(2)Sound amplification output:
Output impedance:600Ω
Output audio level:025Vpp-0.4Vpp
(3)Battery backup supply:24VDC/7Ah
SYSTEM CONFIGURATION
WS824(9)i | |
Name of the expandable board |
Description |
WS824(9)i-main board |
4 co lines ports,4 hybrid extension ports,12 normal exts ports,RS232 ,one route OGM, External Music Port,Page port,440&480Hz Signal tone. |
WS824(9)i-300L trunk line board |
3 ports trunk line board with CID |
WS824(9)i-008C extension board |
8 ports analogue extension board |
WS824(9)i -008A extension board |
8 ports extension board(4 key phones can be connected) |
WS824(9)i -P02 board |
Back-up battery board |
WS824(9) i –IP fuction board |
4 route IP channel |
Special Key Phone
3S Billing Software
Shenzhen Guowei Cesller Technology Co.,Ltd,our headquarter lies in Canada. It is a hi-tech. Company, specializing in manufacturing, developing, selling of group-phone system and communication equipments. The managing idea is to provide continually communication products which joint global communication and synchronize to world communication.
Shipping to worldwide by DHL, FEDEX, TNT and UPS etc.
Lanny Welcome you to ask for price.
Skype: cesller
Wechat:Lanny-Liu
WhatApp:+8615013708905
