128 exts digital exchange for telephone for 16 line

Specifications

128 exts digital exchange for telephone for 16 line
IVR navigation
Call recording software
one year warranty

128 exts analog exchange for telephone for 8  line/ telephone exchange pabx/ telephone line switch





1. Full Digital Exchange and eight ways of NO block for conversation and dialing and there is eight type of codes for dialing out.

2. Can support 2M ( PRI ) board.



3. Can be connected with 80 key phones.

4. Built-in Two mode 75s Six Section Auto-Attendant,can be up to 8 rounts.

5. Incoming Call can be transferred to mobile phone.



6. High Speed for Call Transfer and High Quantity Tone.
Call in one group by one key. When routing in via Auto-Attendant , users calling in will hear suck kind of reminding tone.



7. Call Navigation by One Key.

“Thanks for calling XX company. Please dial extension number directly. Dial “1” for product information , dial “2” for sales after team , dial“3”for shipping. Dial“0”for operator assistance. Can route in relative extensions of one same group and make the extensions ring circularly by the function . Thus, extension will be ringed if it is idle first. So it is very suitable for company, which has plentiful direct customers. Therefore, can improve speed of call handling and reduce incoming call loss , and make transfer more quickly.

8. Mini Calling Center Software
The Software is a kind of multi-function fitting integrates System Accounting, System Monitoring , System Setting and Customer Information Popping. So that customers can manage call system easily and improve efficiency, Also save labor cost and improve satisfaction degree. It is very suitable for sales requirement in different field.





Special Function



1)Professionaltelephone recording system(Optional)



2)Professional IVR voice navigation system(Optional)







3)Intelligent economy routing



WS824(10D)S carriers can provide a variety of trunk interfaces to meet the different operators access.According to user's routing, and call a automatically select the most economical operators, so as to save money for your company.









4)Professional Forward to mobile phone function

    By extension, you can enter manually go outside or extension phones on the outside, just like turn inside telephone convenient;You can also set the phone to automatically turn on the extension, so dial the extension to automatically dial an outside line or extension phone on the conditions on the extension can be set to Phone, conditions immediately turn mobile phones, Busy phones, no one then turn the phone, busy or no access to Phone, etc. by which one also choose to dial the mobile phone, as long as it is installed on the mobile phone access module, installed on the cluster network card, you can not spend money to make or receive call from the company, just bring the phone, where are all the same answer can be like in the office telephone extension or from outside into



5)Built-in Six Sections 75S intelligent computer operator.



The machine has the expansion boards showed as the table:

WS824(10D)S
Name of the expandable board	Description
WS824-(10D)S-800L trunk line board	8 ports trunk line board with CID
WS824-(10D)S-008C extension board	8 ports analogue extension board
WS824-(10D)S-008A extension board	8 ports extension board(4 key phones can be connected)
WS824-(10D)S-P04	Back-up battery board
WS824-(10D)S-M01 board	Mother board



Model	Weight(KG)	Size(mm)
WS824-(10D)S	7.5	425*300*140(L*W*H)

















Specification

Power supply voltage: 11VAC or 220 VAC,50/60 Hz

Maximum power consumption: 80W



Cross-talk attenuation: >70db

Operating temperatures: 0°C to 45°C (32°F to 113°F)

Operating humidity: 10% to 95% without condensation

Feature phone: Maximum 100m(2 pairs twisted wire 0.5@)

Single line phone: Maximum 1,000m(1 pair twisted wire 0.5@)

Connect with PC, connecting length:<30m

(1)Source of music:

Input impedance:600Ω

Input audio level:025Vpp-1Vpp

(2)Sound amplification output:

Output impedance:600Ω

Output audio level:025Vpp-0.4Vpp

(3)Battery backup supply:24VDC/7Ah
