Specifications
SIP IP PABX Phone System with 4 to 88 FXS/FXO portsSIP trunks for least cost calls
100 IP users
Billing,MOIVR,Record
Asterisk IP PBX with 4/88 or 10/72 FX0+FXS, SIP Server inside,support 100 SIP usrs
Automatic Operator ServiceVIP Operator Service
IVR Selection per CPN
Login Authentication & GUIAdministrator account (1)Main Line (3 accounts)Extensions (30 accounts)
Busy Line Indicator
SIP / PSTN Trunking
Extension Calling
Extension RestrictionIntra-Network,
Local, Domestic, and International Calls Direct ,Inward Dialing Emergency
Call Manager/Secretary Functions
Music on Hold
Distinct Ringing
Location Free Extension Dialing
Incoming Call History
Outgoing Call History
Calling Detail Record
Real Time Extension Line Status
Busy/Idle Display Extension/ID Display Presentation Status
Call Transfer
Personal Ring-Back Tones
Call Rejection (Call Cancellation)Selective Call Rejection
Click-to-Dial
Three Way Calling
Phone Book Grouping (User group, FXO group, etc.)
Line Hunt Group (Serial & CircularHunt)
Name/Title Display
Outgoing Line Selection
Hot Line
Custom Dialing PlanLeast Cost Routing
Do Not Disturb
Call Waiting
Call Hold,Hot Line (Instant or Delay)
Speed Dial List (30/Line)
Caller ID Suppression
Outgoing Call BarringCaller ID (Name & Number)
Caller ID on Call Waiting
Specification Parameter
| Size | 430*240*124mm |
| Weight | 3kgs |
| FXx(PSTN) | 4/10 |
| FXO+FXS | 4/88 or 10/72 |
| CDMA/GSM | Optional |
| IP user | 100 |
| IP concurrent | 20 |
IP and Traditional voice concurrent channel |
4 |
| SIP trunk | 9 |
| LAN Port | 1 |
| SIP Protocol | YES |
| Record | Optional |
Power Specification
Power supply voltage: 110VAC or 220 VAC,50/60 Hz
Maximum power consumption: 65W
Operating temperatures: 0°C to 45°C (32°F to 113°F) ,26±5°c for best
Operating humidity: 10% to 95% without condensation
Feature phone: Maximum 100m(2 pairs twisted wire 0.5@)
Single line phone: Maximum 1,000m(1 pair twisted wire 0.5@)
Connect with PC, connecting length:<30m
(1)Source of music:
Input impedance:600Ω
Input audio level:025Vpp-1Vpp
Output impedance:600Ω
(2)Battery backup supply:24VDC/76Ah
Product feature:
1) Smooth transition, compatible with tradition and the future
Inherited the traditional digital switch technology, Realization of the digital switching exchange to smooth over IP, compatible with both traditional digital switching, IP switching and rich terminal interface, allowing users to continue to use that traditional digital switching functions, while experience using advanced IP switching technology.
2) The remote call zero cost
Through IP technology, remote IP phones, computer softphone, soft phone and smart phone company headquarters zero cost of calls between extensions.
Through the IP network to achieve the company's headquarters system with dispersed between the distribution system free fast extension call.
3) WIFI mobile together with wired network
Unique IP extension and desktop extension bundled with vibration function, you can turn your smartphone into a mobile extension.whether you're in the company within the scope of any place, or at home or a business trip with WIFI or 3G environment movement, any person whether it is your customers, or other employees call your desktop extension, your phone IP extension will ring together. Your mobile phone has become a truly mobile IP extension.
You can also use a special WIFI cordless handset as an IP extension. So by the smart phone, WIFI sub-phone into WIFI mobile communication network, and the wired desktop extension, wired IP phones posed fixed wireline communications network will seankssly togerher,to truly improve the communication efficiency of enterprises.
4)The number of unique passthrough
5) Comprehensive generalist
Shenzhen Cesller Technology Co.,Ltd,our headquarter lies in Canada. It is a hi-tech. Company, specializing in manufacturing, developing, selling of group-phone system and communication equipments. The managing idea is to provide continually communication products which joint global communication and synchronize to world communication.
