hydraulic mobile ramp for forklift
(1) Product usage:
hydraulic mobile ramp for forklift is cargo handling auxiliary equipment,is used together
with the forklift.according to car compartments high-low adjustment height, forklift can
directly through this equipment enter into car compartments to unload the goods.only
need one person operate, can realize the rapid loading and unloading goods.It makes
the enterprise to reduce a large number of labor force, improvework efficiency, and gain
greater economic benefit.
(2) Product material design:
Platform uses special diamond mesh plate,has reliable strength,can ensure the long-term
use without deformation.(Its diamond mesh,fully guarantee the excellent anti-skid
performance structure,make forklift have better gradeability and manipulability. Even
in the rain and snow weather, still can ensure normal use.)
Can adjust length of rope chain, and easily hook truck, make hydraulic mobile ramp and truck
always closely jointed.With using of the hand hydraulic pump as dynamic,not need external
power supply,can easily realize the height adjustment of the hydraulic mobile ramp.
The configuration of the brake pad can effectively prevent hydraulic mobile ramp moving when truck
loading and unloading goods.
Note: we can product hydraulic mobile ramp, lifting weight:4-12t, lifting height:0.9-1.7m. we can also make according to customer's special requirements.
(3)The technical prameters of hydraulic mobile ramp:
Model |
Lifting height (m) |
Lifting weight(kg) |
Platform size(mm) |
Overall dimension(mm) |
Power supply(kw) |
Total weight(kg) |
DCQY-4 |
0.9-1.7 |
4000 |
10500*1900 |
10500*2000 |
Manual operation |
2200 |
DCQY-6 |
0.9-1.7 |
6000 |
10500*1900 |
10500*2000 |
Manual operation |
2300 |
|
DCQY-8
|
0.9-1.7 |
8000 |
10500*1900 |
10500*2000 |
Manual operation |
2400 |
|
DCQY-10
|
0.9-1.7 |
10000 |
10500*1900 |
10500*2000 |
Manual operation |
2600 |
|
DCQY-12
|
0.9-1.6 |
12000 |
10500*1900 |
10500*2000 |
Manual operation |
2800 |
....
Related Products
Jinan Jinchuan hydraulic machinery co., LTD is a collection research and development, production, sales in the integration of local industry company, for decades of production experience, has its own sales team and after-sales service team. Jinchuan since was established, taking the tenet of "honesty, science and technology innovation" and the concept of "quality first, users first", adhere to go today! Jinchuan will always be with full mental state to meet your arrival! Welcome!
Packing:
We always make the lift machine packed inner with wrap film and outer with plywood case. The plywood case is free of steaming kaori, and it is exempted from inspection products, save a lot of trouble in the process of export or import.
