40W Square Led Panel Light 60 60 Ultra-thin Flat Panel Led Lighting

40W Square Led Panel Light 60 60 Ultra-thin Flat Panel Led Lighting thumbnail-1
40W Square Led Panel Light 60 60 Ultra-thin Flat Panel Led Lighting photo-1
US$ 12 - 21 MOQ: 100 Pieces
Key Specifications
Get Latest Price
LED Light Source:
SMD4014
Warranty(Years):
2
Input Voltage(V):
220V
Contact Supplier Request Quote Chat Now
Hangzhou Areeklighting Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
LED Light Source SMD4014
Warranty(Years) 2
Input Voltage(V) 220V
Lamp Power(W) 40
Lamp Luminous Flux(lm) 3500
Lamp Luminous Efficiency(lm/w) 90
Color Temperature(CCT) Other, All available
Working Temperature(℃) -40, 50
Working Lifetime(Hour) 50000
Lamp Body Material Aluminum
IP Rating Other, 20
Certification CCC, CE
Place of Origin Zhejiang, China
Brand Name Ireed
Model Number AR-PL6060B

   Thanks for your time to visit the following things,if any questions,pls contact with me. Have a nice day

Product Description

40W square led panel light 60 60 ultra-thin flat panel led lighting

 Size: 595*595*10mm

Luminous Flux :3500lm

Power: 40w

Voltage: 110~240V

QTY of package per carton:5pcs40W square led panel light 60 60 ultra-thin flat panel led lighting

 40W square led panel light 60 60 ultra-thin flat panel led lighting

40W square led panel light 60 60 ultra-thin flat panel led lighting40W square led panel light 60 60 ultra-thin flat panel led lighting

40W square led panel light 60 60 ultra-thin flat panel led lighting

40W square led panel light 60 60 ultra-thin flat panel led lighting40W square led panel light 60 60 ultra-thin flat panel led lighting



Model No Power Size(mm) Led qty Luminous Flux  Working Voltage Qty per carton N.W.(KG) G.W.(KG) Carton size(cm)
AR-PL3060A 20-22W 295*595*10 100P 1600lm 100-240V 10 14 17 66*53.5*36.5
AR-PL3060B 24-26W 295*595*10 120P 1920lm 100-240V 10 14 17 66*53.5*36.5
AR-PL6060A 32-36W 595*595*10 160P 2560lm 100-240V 5 15 18 67*28*67
AR-PL6060B 36-40W 595*595*10 180P 2800lm 100-240V 5 15 18 67*28*67
AR-PL6060C 40-45W 595*595*10 204P 3200lm 100-240V 5 15 18 67*28*67
AR-PL6060D 48-54W 595*595*10 240P 3800lm 100-240V 5 15 18 67*28*67
AR-PL6060E 60-65W 595*595*10 324P 4500lm 100-240V 5 15 18 67*28*67
AR-PL30120A 40-45W 295*1195*10 204P 3200lm 100-240V 5 16 19 127*26*37
AR-PL30120B 48-52W 295*1195*10 240P 3800lm 100-240V 5 16 19 127*26*37
AR-PL30120C 60-65W 295*1195*10 324P 4500lm 100-240V 5 16 19 127*26*37
AR-PL60120 60-65W 595*1195*10 324P 4500lm 100-240V 5 30 40 130*32*71.5



led panel light Application

a, Indoor ceiling lighting. Bookcase. Cupboard window.
b, Schools, hospitals, churches, office buildings.
c, Office, factory floor, conference room lighting sources.
d, Shopping malls and fine cabinets, jewelry, cosmetics counters counter.
e, Commercial shops.
f, Bars, hotels, discos, kara OK liquor counter.


40W square led panel light 60 60 ultra-thin flat panel led lighting40W square led panel light 60 60 ultra-thin flat panel led lighting40W square led panel light 60 60 ultra-thin flat panel led lighting 40W square led panel light 60 60 ultra-thin flat panel led lighting

led panel light Advantages:

1. 85% Energy saving powered by SMD led.

2. Glare-free lighting and even brightness by Edge-lighting, using high quality light-guide plate.

3. Really high power efficiency.

4. Special circuit layout and good heat dissipation ensure light’s long lifespan.

5. Color of housing can be optional.

6. No cost of maintenance and easy installation.

7. Environmentally friendly.

 40W square led panel light 60 60 ultra-thin flat panel led lighting



Quality Control

1. 100% testing before aging . During the aging procedure, the switch is off-on automatically every 2minutes to make sure the quality .

2. 100% testing by safe tester (with high voltage) before packing.



40W square led panel light 60 60 ultra-thin flat panel led lighting



Packaging & Shipping

QTY per carton: 5pcs

Outer Carton size (cm): 67*28*67

40W square led panel light 60 60 ultra-thin flat panel led lighting

Our Services

1. Yours own design are acceptable.
2. 3 years warranty.
3. Labling, Packing Service.
4. Samples will be gald to send for your reference.
5. Reply yours questions within 24 hours.
6. Small Orders are acceptable for the long cooperation.

7. Protection of your sales area,ideas of design and all your private information.
