Specifications
Wide temperature range,from800C to 1400CFirm, reliable anchor
Install easily and quickly
Productive Technology:
Anchor is a kind of structure which joint and fix between the ceramic fiber products,insulating fire brick,amorphous refractory with the kiln metal wall plate.According the kiln structure,furnace temperature and atmosphere,we should select and use different structures and materials anchors.
Characters:
1. Wide temperature range,from800C to 1400C
2. Various shapes
3. Reasonable structure
4. Firm, reliable anchor
5. Install easily and quickly
Applications:
1. Fix ceramic fiber modules and folded modules
2. Fix all kinds of refractory brick and cement castable
3. Anchor fiber flame plating
4. Fix and joint high temperature board and installation
Technical Index
Product Type | Anchor Products | |
Classification Temperature (°C ) | 1260 | 1400 |
Name | U-form penetration nail, instant card, rotation card, penetration rod, screw, nut V-form rame , angle iron anchor, butterfly anchor, diamond anchor, hole suspending anchor, corner anchor | |
Code | 304S Series | 310S Series |
Application Temperature (°C) | 870 | 1035 |
Delivery State | Formed a complete set | |
Packing | Wooden Box | |
Technical Criteria | 0Cr18Ni9 | Cr25Ni20 |
