Elbow Pipe Heat Resistant Covering

Negotiable MOQ: 100 Pieces (Price negotiable depending on order volume and customization)

Key Specifications

Business Type:

Trading Company

Year Established:

2009

Factory Size:

Below 1,000 square meters

Payment & Shipping

Payment Methods:

Port of Shipment:

QINGDAO

Delivery Detail:

Delivery time depends on order quantity.

Specifications

1.ceramic fiber blanket with glass fiber cloth and ss wire
2.Used in the elbow pipe
3.Service temperature:1000C
4.Nice face

Ceramic fiber blanket

Description

1.YAOXING Ceramic Fiber Blanket was adopted continuous processing method,

the fiber interweaved shapely after being needled,which of excellent tensile strength.

The blanket contains not any bonding agent .

2.Our needled blanket has various density and thickness

so that our client can have many choices, which will bring the perfect insulating framework and profit.

3.YAOXING Ceramic Fiber Blanket can resist the chemical species well,

but not the Hydrofluoric Acid, Phosphoric Acid and Strong Base.

4.YAOXING Ceramic Fiber Blanket have excellent capability of resisting the oil,

after being dried it will repossess the thermal characteristic and the physical feature.

Characteristic

1.Excellent Chemical Stability

2.Excellent Thermal Stability

3.Excellent Tensile Strength

4.Low Thermal Conductivity

5.Low Heat Storage

Application

The material of wall lining and back lining of industrial furnace and the sealing

and insulation material of expanded gaps of furnace wall, furnace door, furnace top lid, etc.

Insulating material of high temperature

Excellent materials to produce module and folded module

Technical Index

Classification Temperature	1050	1260						1400
Code	TXTX-112	TXTX-212			TXTX-312			TXTX-422			TXTX-512
Shrinkage on Heating (%)	950°C×24h≤-3	1000°C×24h≤ -3			1100°C×24h≤-3			1200°C×24h≤-3			1350°C×24h≤-3
Theoretical Thermal Conductivity (W/m·k)(128kg/m3)	0.09(400°C) 0.176(800°C)	0.09(400°C) 0.176(800°C)			0.09(400°C) 0.176(800°C) 0.22(1000°C)			0.132(600°C) 0.22(1000°C)			0.76(600°C) 0.22(1000°C)
Theoretical Density (kg/m3)	64/96/128
Specification (mm)	7200/5000/3600/3000×610/1220×/20/30/40/50 According to your requirements
Tensile Strength (Mpa)(128kg/m3)	0.08-0.12
AL2O3(%)	≥44	≥45		≥45			52~55			38~40
ZrO2	-									15~17
AL2O3+SiO2(%)	≥96	≥97	≥99			≥99			—
AL2O3+SiO2+ZrO2(%)	—	—	—			—			≥99
Fe2O3(%)	≤1.2	≤1.0	≤0.2			≤0.2			≤0.2
K2O+Na2O(%)	≤0.5	≤0.5	≤0.2			≤0.2			≤0.2
Package	Plastic Bag Inside, Woven Bags Outside
Quality Control System	ISO9001-2000, ISO14001-1996
