Help CenterHeat Shield Used in the the Oil Industry
Related Products
-
Fireproof Heat Insulation Cover With Ceramic Fiber Glass Fiber and ss WireNegotiableMOQ: 100 Pieces -
Heat Preservation Cover With Ceramic Fiber Blanket Used in the Worm WheelNegotiableMOQ: 100 Pieces
-
Ceramic Fiber Blanket Heat Insulation MeshNegotiableMOQ: 100 Pieces
-
Aluminum Silicate Ceramic Fiber BlanketNegotiableMOQ: 100 Pieces
-
Heat Preservation Blanket Heat Insulation ShieldNegotiableMOQ: 100 Pieces
Specifications
1.ceramic fiber blanket with glass fiber cloth and ss wire2.Used in the oil industry
3.Service temperature:1000C
4.Nice face
Ceramic fiber blanket
Description
1.YAOXING Ceramic Fiber Blanket
was adopted continuous processing method,
the fiber interweaved shapely after being needled,
which of excellent tensile strength.
The blanket contains not any bonding agent .
2.Our needled blanket has various density and thickness
so that our client can have many choices,
which will bring the perfect insulating framework and profit.
3.YAOXING Ceramic Fiber Blanket can resist the chemical species well,
but not the Hydrofluoric Acid, Phosphoric Acid and Strong Base.
4.YAOXING Ceramic Fiber Blanket
have excellent capability of resisting the oil,
after being dried it will repossess the thermal characteristic
and the physical feature.
Characteristic
1.Excellent Chemical Stability
2.Excellent Thermal Stability
3.Excellent Tensile Strength
4.Low Thermal Conductivity
5.Low Heat Storage
Application
The material of wall lining and back lining of industrial furnace and the sealing
and insulation material of expanded gaps of furnace wall, furnace door, furnace top lid, etc.
Insulating material of high temperature
Excellent materials to produce module and folded module
Technical Index
Classification Temperature | 1050 | 1260 | 1400 | ||||||||
Code | TXTX-112 | TXTX-212 | TXTX-312 | TXTX-422 | TXTX-512 | ||||||
Shrinkage on Heating (%) | 950°C×24h≤-3 | 1000°C×24h≤ -3 | 1100°C×24h≤-3 | 1200°C×24h≤-3 | 1350°C×24h≤-3 | ||||||
Theoretical Thermal Conductivity (W/m·k)(128kg/m3) | 0.09(400°C) 0.176(800°C) | 0.09(400°C) 0.176(800°C) | 0.09(400°C) 0.176(800°C) 0.22(1000°C) | 0.132(600°C) 0.22(1000°C) | 0.76(600°C) 0.22(1000°C) | ||||||
Theoretical Density (kg/m3) | 64/96/128 | ||||||||||
Specification (mm) | 7200/5000/3600/3000×610/1220×/20/30/40/50 According to your requirements | ||||||||||
Tensile Strength (Mpa)(128kg/m3) | 0.08-0.12 | ||||||||||
AL2O3(%) | ≥44 | ≥45 | ≥45 | 52~55 | 38~40 | ||||||
ZrO2 | - | 15~17 | |||||||||
AL2O3+SiO2(%) | ≥96 | ≥97 | ≥99 | ≥99 | — | ||||||
AL2O3+SiO2+ZrO2(%) | — | — | — | — | ≥99 | ||||||
Fe2O3(%) | ≤1.2 | ≤1.0 | ≤0.2 | ≤0.2 | ≤0.2 | ||||||
K2O+Na2O(%) | ≤0.5 | ≤0.5 | ≤0.2 | ≤0.2 | ≤0.2 | ||||||
Package | Plastic Bag Inside, Woven Bags Outside | ||||||||||
Quality Control System | ISO9001-2000, ISO14001-1996 | ||||||||||
Glass fiber cloth
Description:
Glass fiber cloth is a kind of project materials.
Characteristics:
1. Non-combustible
2. Corrosion resistant
3. High temperature resistant
4. SmallSuck temperature
5. Small coefficient of deformation
Application:
Widely used in the lectrical appliances, electronic,
transportation, chemical engineering, construction engineering,
heat insulation absorption, fire control and environmental protection
