heat insulation refractory brick furnace brick

Specifications

1.lining furnace brick
2.Temperature:1300C-1600C
3.Grade: 23,26,28,30
4.Heat Insulation
5.vacuum and sintered



Mullite Fire brick



Grade: 23,26,28,30
Size:230x114x65mm,230x114x76mm
Temperature: 1300c-1600c



Description

1.YAOXING lightweight mullite fire brick is made from high-grade

and high purity refractory powders and materials.

2. During the process of production, organic and multiple filling materials

are injected according to the required proportion.

3.YAOXING mullite brick is compressed in vacuum

and sintered under high temperature conditions.



Application

1.Lining and back lining of various furnaces in the industry of metallurgy,

petrochemical, ceramics, machinery and building materials.

2.The cracking furnace, conversion furnace, heating equipment, refining

equipment, reproduction equipment, hot blast stove, heating furnace, even-heating furnace,

heat-processing furnace,resisitance furnace, tunnel kiln, shuttle kiln, bell-cover kiln, glass-pool-kiln,etc.

Technical Index

Product	Mullite Fire brick
Classification Temperature	1300-1600
Density(kg/m3)	600-1100
Reheat change (%)	1230-1600C x 3h ≤ 0.5~0.8
Tensile strength (Mpa)	1.1-4.8
Expansion on heating (1000C)(%)	0.5-0.6
Thermal conductivity(350C)(W/m.k)	0.16-0.43
Al2O3(%)	≥38-79
Fe2O3(%)	≤0.5-1.0
Specification(mm)	230*114*65
Packing	10 pcs/ carton box,  1000pcs/pallet





 Customized production is also available, please contact us for more information!
