heat insulation welding fabric high silica cloth glass fiber silica fabric

Specifications

1.Heat insulation welding fabric
2.Weight:1250g/m2
3.Size:1.3x860X50000mm
4.Working Temp:1000C



High Silica Cloth



Characteristic:



1.YAOXING high silica cloth is a kind of high temperature resistant inorganic fibers

2.The highest temperature near 1700°C and its working temperature is 1000°C.

3.Easy to machining,and widely used material.

It can be as heat resistant,ablative resistance heat insulation material,high strength



Application:



1.Heat-resistant,heat-preservation and sealing material

2.High temperature gas,liquid,dust filter

3.Fireproof material (fireproof clothing,fire resisting curtain and so on)

4.High temperature metalic solution filtered

5.Welding heat insulation protection material

6.Noise reduction,insulation exhaust filter of the auto and motorcycle

7.Heat-preservation and ablation materials of the rockets, missile and spacecraft



Technical Index:



Product Code	Thickness(mm)	Width(mm)	Content of the SiO2(%)	Woven Organization
YXBX-100	0.10	80-90	≥96%	Plain Weave
YXBX-260	0.26			Plain Weave
YXBX-600	0.65	80-1200		Satin Weave
YXBX-1250	1.3			Satin Weave



The High Silica Cloth can be woven into many forms,such as yarn,rope and so on.
