1260C 550K Ceramic Fiber Tape for High Temperature Industrial

Zibo Yao Xing Fire-Resistant And Heat-Preservation Material Co., Ltd.
1260C 550K Ceramic Fiber Tape for High Temperature Industrial thumbnail-1
1260C 550K Ceramic Fiber Tape for High Temperature Industrial thumbnail-2
1260C 550K Ceramic Fiber Tape for High Temperature Industrial thumbnail-3
1260C 550K Ceramic Fiber Tape for High Temperature Industrial thumbnail-4
1260C 550K Ceramic Fiber Tape for High Temperature Industrial thumbnail-5
1260C 550K Ceramic Fiber Tape for High Temperature Industrial thumbnail-6
1260C 550K Ceramic Fiber Tape for High Temperature Industrial photo-1
1260C 550K Ceramic Fiber Tape for High Temperature Industrial photo-2
1260C 550K Ceramic Fiber Tape for High Temperature Industrial photo-3
1260C 550K Ceramic Fiber Tape for High Temperature Industrial photo-4
1260C 550K Ceramic Fiber Tape for High Temperature Industrial photo-5
1260C 550K Ceramic Fiber Tape for High Temperature Industrial photo-6
Negotiable MOQ: 1000 Meters (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Application:
Refractory
Thickness:
2mm
Width:
50mm
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Application Refractory
Thickness 2mm
Width 50mm
Length 3000mm
Grade ST (Standard)
Chemical Composition Ai2O3 SiO2
Working Temperature 1050
Fiber Diameter 3um
Thermal Conductivity 0.075
Shrinkage (1800℉, 3h) ≤3%
Place of Origin Shandong, China
Brand Name Yaoxing
Model Number YXTX-208B1

Specifications

1.ceramic fiber tape
ing temp:1260C
3.density:550K
4:application:for High temperature Industrial


Product Description



Ceramic Fiber Tape :

1.YAO XING 1260 ceramic fiber tape is a costeffective insulating tape

made from ceramic fiber yarn,reinforced by a core of glass filament

or stainless steel wire for high strength retention at elevated temperatures,

ideal for most high temperature applications up to 1260°C.

2.YAO XING 1400 tape is a high performance industrial tape

made from zirconia grade ceramic fiber yarn, reinforced by high temperature alloy wire.

It is durable, long-lasting product, ideal for high temperature applications up to 1400°C.

3.YAO XING tape contains approximately 18% organic fiber

which burns out at high temperatures, causing some smoking and outgassing,
but the tape retains enough strength to be used as effective insulating cloth at high temperatures.

Characteristics:

1.Excellent high-temperature strength

2.Excellent electric insulation capability

3.Excellent corrosion resistance to acid oil and steam

4.Low thermal conductivity

5.Excellent thermal insulation capability

Applications:

1.Furnace curtains

2.Protection against high temperature

3.High temperature electrical insulation

4.Cable and fuel line protection

5.Fire protection

6.Insulation of industrial chimney

Technical Index:



Classification Temperature

1260C

Product

1260 ceramic fiber tape

Code

YXTX-208B1

YXTX-208B2

Service Temperature(°C)

450

1000

Basic Material

Ceramic fiber

/glass fiber reinforced

Ceramic fiber

/ stainless steel reinforced

Theoretical Density (kg/m3)

600

Specification (mm)

3000×20/50/75/100×2/3

Moisture Content(%)

≤2

Warp Density

56-60piece/10cm

Weft Density

24-30piece/10cm

Organic Content (%)

≤15

 1260C 550K Ceramic Fiber Tape for High temperature Industrial1260C 550K Ceramic Fiber Tape for High temperature Industrial1260C 550K Ceramic Fiber Tape for High temperature Industrial1260C 550K Ceramic Fiber Tape for High temperature Industrial1260C 550K Ceramic Fiber Tape for High temperature Industrial1260C 550K Ceramic Fiber Tape for High temperature Industrial
