Help CenterMolybdenum Plate(99.95%)
Related Products
Specifications
molybdenum plate is used for heater of electronic vacuum furnace and heat-insulation screen,molybdenum plate is used for heater of electronic vacuum furnace and heat-insulation screen, Molybdenum round sheet to produce
Molybdenum boat and electric power semiconductor, raw materials to make vacuum light house.Forming the molybdenum powder with isostatic pressing, and with the technology of hot rolling, annealing, washing with alkali, cold rolling ,cutting,leveling off after the molybdenum sheet billet is formed by sintering with medium frequency furnace, molybdenum sheets have the excellent characteristic of brightness and smoothness on the surface and well reprocessing.
We can provide various of these products in types such as hot/cold rolling, stress relief, single direction rolling and across rolling with the thickness among 0.1~20mm and the width up to 600mm.As one of the enterprises earliest engaged in developing and producing molybdenum sheet in China, we fetched into advanced production technology, imported high-powder multi-roller wide rolling mill and intermediate frequency sintering equipments to satisfy different requirement.Our products with annual capacity up to 20 tons sell well all over China and are exported to every quarter of the globe in large quantity . the molybdenum round sheets with the diameter among 15~55mm, the thickness among 0.5~5.5mm and the surface finish of 6 ,which are principally used in pad of thyristor, is one of our excellent products .every guide line of this kind of products excel the national level.
Trade mark |
specification |
Specification |
|||||
Thickness |
thickness tolerance level 1 |
width |
Width tolerance level 1 |
length |
Length tolerance level 1 |
||
Mo1 |
0.100.15 |
±0.01 |
≤350 |
±2 |
≤1300 |
±5 |
There are Cold/hot rolling and stress relief state. When order, please tell us the usage and the require, we can make it as your require size |
>0.160.30 |
±0.02 |
≤350 |
±2 |
≤1300 |
±5 |
||
>0.310.50 |
±0.03 |
≤600 |
±5 |
≤1300 |
±5 |
||
>0.510.70 |
±0.04 |
≤600 |
±5 |
≤1300 |
±5 |
||
>0.711.00 |
±0.05 |
≤600 |
±5 |
≤1300 |
±5 |
||
>1.012.00 |
±0.06 |
≤600 |
±5 |
≤1300 |
±5 |
||
>2.013.00 |
±0.08 |
≤400 |
±3 |
≤1000 |
±5 |
||
>3.014.00 |
±0.10 |
≤400 |
±3 |
≤1000 |
±5 |
||
