Home > Chemicals > Inorganic Fiber > Ceramic Fiber > Stove Backing Ceramic Fiber Modulesrefractory Ceramic Fiber Module Ceramic Wool Block

Stove Backing Ceramic Fiber Modulesrefractory Ceramic Fiber Module Ceramic Wool Block

Name: Stove Backing Ceramic Fiber Modulesrefractory Ceramic Fiber Module Ceramic Wool Block
Brand: YAOXING
SKU: 102720359
Availability: InStock

$Stove Backing Ceramic Fiber Modulesrefractory Ceramic Fiber Module Ceramic Wool Block thumbnail-1$

$Stove Backing Ceramic Fiber Modulesrefractory Ceramic Fiber Module Ceramic Wool Block thumbnail-2$

$Stove Backing Ceramic Fiber Modulesrefractory Ceramic Fiber Module Ceramic Wool Block thumbnail-3$

$Stove Backing Ceramic Fiber Modulesrefractory Ceramic Fiber Module Ceramic Wool Block thumbnail-4$

$Stove Backing Ceramic Fiber Modulesrefractory Ceramic Fiber Module Ceramic Wool Block thumbnail-5$

$Stove Backing Ceramic Fiber Modulesrefractory Ceramic Fiber Module Ceramic Wool Block thumbnail-6$

$Stove Backing Ceramic Fiber Modulesrefractory Ceramic Fiber Module Ceramic Wool Block photo-1$

$Stove Backing Ceramic Fiber Modulesrefractory Ceramic Fiber Module Ceramic Wool Block photo-2$

$Stove Backing Ceramic Fiber Modulesrefractory Ceramic Fiber Module Ceramic Wool Block photo-3$

$Stove Backing Ceramic Fiber Modulesrefractory Ceramic Fiber Module Ceramic Wool Block photo-4$

$Stove Backing Ceramic Fiber Modulesrefractory Ceramic Fiber Module Ceramic Wool Block photo-5$

$Stove Backing Ceramic Fiber Modulesrefractory Ceramic Fiber Module Ceramic Wool Block photo-6$

Negotiable MOQ: 100 Pieces (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Place of Origin:

Shandong, China

Brand Name:

YAOXING

Model Number:

YXTX-489

Contact Supplier Request Quote Chat Now

Zibo Yao Xing Fire-Resistant And Heat-Preservation Material Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

QINGDAO

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Shandong, China

Brand Name YAOXING

Model Number YXTX-489

Application Liners Of Industrial Furnace, Heat Insulation

Grade HA (High Aluminum)

Working Temperature 1200℃

Fiber Diameter 3μm

Thermal Conductivity 0.050-0.060

Product Description

Characteristic

Ceramic fiber folded module not only used in furnace, but also brought following benefit with ended custom

Folded blanket will impact tight with each other in differently way without gaps after release from packing.
Elastically fiber blanket can withstand mechanical force.
The elasticity of fiber blanket could make up distortion of furnace casing and with gaps between modules.
Because of the light weight, the decalescence capability is low as the insulation materials.
Low thermal conductivity can save much energy.
Excellent thermal shock resistance capability.
Can be betaken immediately as soon as being installed, for there is no need to be dried and maintained.
The Anchor system should be far away from the hot surface of the modules and kept in the lower temp.

Technical Index

Classification Temperature	1050	1260		1400
Code	YXTX-189	YXTX-289	YXTX-389	TXTX-489	TXTX-589
Shrinkage on heating (%)	950°C×24h ≤-3	1000°C×24h ≤-3	1100°C×24h ≤-3	1200°C×24h ≤-3	1350°C×24h ≤-3
Theoretical Density (kg/m³)	200±10
Shot content (φ≥0.25mm)(%)	≤15
Theoretical Thermal Conductivity (W/m·k)	0.050-0.060(200°C)
	0.095-0.120(400°C)
	0.160-0.195(600°C)
Al₂O₃(%)	≥44	≥45	≥45	52-55	38-40
Al₂O₃+SiO₂(%)	≥96	≥97	≥99	≥99	-
ZrO₂(%)	-	-	-	-	15-17
Al₂O₃+SiO₂+ ZrO₂(%)	-	-	-	-	≥99
Fe₂O₃(%)	≤1.2	≤1.0	≤0.2	≤0.2	≤0.2
K₂O+Na₂O (%)	≤0.5	≤0.5	≤0.2	≤0.2	≤0.2
Specification (mm)	300×300×200,According to your requirements
Package	Woven Bag/Carton
Quality Control System	ISO9001-2000 ,ISO14001-1996
