1. cable float level switch product description
cable float switch is the use of micro-switches or reed contact switch to do , when to hammer origin cable float upward at an angle ( usually micro switch upward angle of 28 ° ± 2 °,), the switch will that the ON or OFF signal.
one type is the use of plastic injection molding , it is rugged , reliable performance, while non-toxic , corrosion resistance, easy installation , low cost, multi-point control of long-distance , heavy pumps, there are fluctuations in the liquid or liquid impurities control good effect. General liquid can also be used . Cable lengths and special material requirements can be customized.
2.cable float level switch Features
Leading design and strict manufacturing process for the product quality to provide a reliable guarantee.
Shell is made of plastic or ABS, high mechanical strength , good sealing .
Simple structure, reliable performance. Output stable and reliable "on" , "off" switch control signal , without any malfunction , and high reliability.
Installation is simple, easy to debug , move up and down positioning weights, you can freely adjust the control range.
3. cable float level switch Technical parameters
Rated current: Voltage : (4A) 220V inductive load
Cable wire :1mm2 Red copper wire OD8.5
Switch type: Import Micro switch
New material stronger and harder
Silicone cable Current heater: 250v 10A
IP65
Cable length : 1-40M
Under 1100W power pump could be directly use.
Life time :50,000times
Control range:>0.3m
Rated power : 1.5KW;
Working temperature: -10 degrees Celsius to 80 ( plastic ) degrees ;
Working pressure: 1 atm ;
Suitable medium : water, sewage , oil and moderate concentrations below pH liquids.
Cable length : Standard delivery length of 2 m , special lengths can be customized.
Wide application range and strong generality:
The product can be used to the level of sewage, acid-base solution of less than medium concentration, oils and situations requiring no pollution, diesel oil gasification kitchen range, as well as automatic fuel feeding.
Package Includes:
1 x cable float level switch
Simple Construction, reliable performance:
The product can output stable and reliable switch control signal of “making”, “breaking” without any fault action, so its reliability is very high and anti-interference is strong.
Sturdy and durable, need not maintain:
The product can be sued for a long time after it being in stalled. Almost no maintenance and repairing problem would occur during its operation period.
Easy to install and convenient to adjust:
The liquid level control scope can be adjusted at will with the locating piece moving up and down. Only one screw is needed to faSPen the signal cable to finish installation.
Wide application range and strong generality:
The product can be used to the level of sewage, acid-base solution of less than medium concentration, oils and situations requiring no pollution, diesel oil gasification kitchen range, as well as automatic fuel feeding.
Any inquire,please contact with us.
We will reply you in 24 hours.©
