Single Mast Mobile Hydraulic Folding Lift Table

Name: Single Mast Mobile Hydraulic Folding Lift Table
Brand: jinchuan
SKU: 102711737
Availability: InStock

US$ 2,000 - 2,600 MOQ: 1 Set

Key Specifications

Place of Origin:

Shandong, China

Brand Name:

jinchuan

Model Number:

SJYL0.1-10

Jinan Jinchuan Hydraulic Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Shandong, China

Brand Name jinchuan

Model Number SJYL0.1-10

Lift Mechanism Telescoping Lift

Lift Drive / Actuation Electric Motor

Power 1.1

Rated Loading Capacity 100kg

Min. Lifting Height 1.5m

Max. Lifting Height 10m

Table Size 550mm*550mm

Overall Dimensions 1500*870*2300mm

Weight 480kg

Certification ISO9001

Warranty 12 months

Specifications

Aluminum lift platform electric single mast lift
1.Height:6000-10000mm
2.Working height:7700-11700mm
3.Capacity: 100kg

Advantages

The single mast mobile lifting equipment has the following characteristics:

1.Lift or fall steadily: The seamless transmission is used between the lifting masts, thus minimizing the amount of sway after lifting.

2.Safe and reliable: The four turning stabilizers of the unit connected to the four corners of the chassis support the MEWP during work.

They are designed for leveling regulation and preventing inclination. They are composed of stand bars and turning legs.

The stand bars are installed in the turning legs. Extending out the turning legs before operating the unit enlarges the area of supporting.

Therefore, the steadiness of the whole platform is guaranteed.

3.Convenient: The whole work platform is light because the lifting masts are made of alloy aluminum.

The structure is compact and the volume is small, so only one person can move the equipment and carry it through a very narrow place.
