Specifications
1 Aluminium lift2 Height :8m electrical elevator
3 Single mast lift
4 Make your work safer and effcient
Introduction:
SJYL Series aluminum mast personnel work platform. One worker can climb in the platform and get straight to work. It can be transported by a single person upstairs, through doorways or in the back of a vehicle. It especially suits working in the narrow spaces. It is more productive and safer than traditional ladder.
Advantage:
It is widely used in factories, hotels, restaurants, station, cinemas, theaters, exhibition hall and other places,is the maintenance tools, paint decoration, change lamps, electrical appliances, cleaning and maintenance etc. best safety partner.
Double mast aluminum alloy lift:
A new design of a new generation products,the whole equipment uses high strength aluminum alloy section bar make.Due to the section bar with high strength,make the deflection and the oscillation amplitude of the lift small.use double mast type structure,load capacity big,platform area is large,good stability,mobile flexible.the lightsome appearance can play to the highest lifting capacity in tiny space.This lift is widely used in workshop, hotels, mansion, shopping malls, railway stations, airports, stadium, etc.
Its parameters and models for your choice
Item |
SJYL0.1-6 |
SJYL0.1-8 |
SJYL0.1-10 |
|
Capacity(kgs) |
100 |
|||
Min.Lifting height(m) |
1.98 |
1.98 |
2.3 |
|
Max.Lifting height(m) |
6 |
8 |
10 |
|
Working Height(m) |
7.5 |
9.5 |
11.5 |
|
Platform size(m) |
0.55*0.55 |
0.55*0.55 |
0.55*0.55 |
|
Overall dimension(m) |
1.26*0.8*1.98 |
1.4*0.85*1.98 |
1.5*0.87*2.3 |
|
Net weight(kg) |
380 |
450 |
480 |
|
|
Power |
Current |
AC |
||
Voltage |
220 |
|||
Kilowatt |
0.75/1.1 |
|||
Phase |
2 |
|||
Main material |
High strength aluminum alloy |
|||
Frame materail |
High strength steel |
|||
Oil cylinder |
Accurate grinding hydraulic oil cylinder |
|||
Power supply |
Italian joint venture pumping station |
|||
Control mode |
Using control pane and control box,all ok! |
|||
Picttures show
Our other similar products for your choice
|
|
|
erial Vertical Mast Lift 1.Ease of elevation—Raise the work platform with hydraulic and electrical system or optional battery motor 2.Superior lifting strength and sturdy base—rigid aluminum mast, heavy-duty lifting chains and a 3.welded steel base that stands up to tough jobsite conditions. 4.Can be powered using 220/380 volt or optional battery power pack 5.Manual emergency decent 6.Manual pushed type and optional self-propelled type 7.Compact storage
|
movable scissor hydraulic lifting platform 1.Scissor hydraulic lift is the professional high-altitude operation equipment. 2.Its scissor mechanical structure makes the lifting platform lift more stably.Wide working platform and large loading capacity can make the work scope bigger.It's suiable for several pelople working together. 3.Lifting height: 4m ,6m, 8m,10m ,11m and so on. And the max height of the scissor lift is 18m. 4.Loading capacity: 300kg,500kg,800kg,1000kg and so on. The Max capacity could be 7000kg. 5.Control method is manual control and electric control. |
