excavator long reach arm is used for dredging rivers, port construction, railway construction and groundwork construction, with high extensive operation scope, high efficiency and high security
The parameters of two-section excavator long reach arm
MODEL |
DLKE1200 |
DLKE2000-1 |
DLKE2000-2 |
DLKE3000 |
DLKE3500-1 |
DLKE3500-2 |
DLKE4500 |
Suitable excavator (ton) |
12 |
20 |
20 |
30 |
35 |
35 |
45 |
Total length (mm) |
13000 |
15380 |
18000 |
18000 |
20000 |
22000 |
24000 |
Weight (kg) |
3000 |
4000 |
4200 |
5200 |
6000 |
6500 |
7000 |
Max dig depth (mm) |
9000 |
11340 |
12200 |
12200 |
14500 |
16100 |
18000 |
Maximum extensive scope(mm) |
12500 |
15100 |
17600 |
17600 |
19600 |
21600 |
23600 |
Max dig height (mm) |
11300 |
12510 |
13500 |
13720 |
14920 |
16100 |
17300 |
Folding height (mm) |
2900 |
2980 |
3040 |
3210 |
3210 |
3400 |
3400 |
Bucket volume (m3) |
0.3 |
0.6 |
0.4 |
0.4 |
0.5 |
0.6 |
0.6 |
Fig 1 the excavator long reach arm
Fig 2 the excavator long reach arm
Fig 3 the excavator long reach arm
- excavator long reach arm will be packaged by plywood case
- delivered within 14 working days after order
Limited 6 month warranty of excavator long reach arm
One-stop service
JISAN HEAVY INDUSTARY
JISAN is modernized excavator attachment manufacturer. We are specialized in R&D, production and sale a wide range of excavator front-end attachments such as hydraulic grapple,excavator long reach, hydraulic hammer,quick hitch,hydraulic grab bucket,hydraulic compactor,ripper,hydraulic breaker etc. As an original manufacturer, we are able to offer you an attractive price and high quality products.
Our products are widely used for earthmoving ,building demolition,mining,paving road,landscape planting,scrap,dispose waste,sub grade compaction etc.
JISAN HEAVY INDUSTARY is striding toward the world first-class enterprise. We are looking forward to establish closed business relation with you on the multiple benefits basic.
Why us?
Attractive price
Excellent quality
Prompt delivery
Intelligence technical team
Professional sale force
I wish meet you at BAUMA EXPRO 2014 in Shanghai
