Rotating Log Bucket Grapple for Doosan CAT Excavator

Specifications

1.Rotating Hydraulic Wood Grapple
2.Apply excavator:17-23ton
3. With Korean body part, made in China, so with high quality







Rotating Wood Grapple

1. Enclosed cylinder check valve installed to prevent the drop of holding material.

2. Lever controlled operation facilitates loading and unloading of logs.

3. Minimized hydraulic trouble which may occur during rotating works.

4. Operator can control the rotating speed.

5. Oil flow control valve and motor protection mechanism applied.

6. Unlimited clockwise and anti-clockwise 360° rotatable

7. Specially designed swing bearing for durability and big cylinder for more power.

8. Wear resistant special solid steel (PT60 from POSCO) is used and no extra reinforcement is requirement.

9. Flexible choices dependent on job requirement.



MODEL	DLKL03	DLKL04	DLKL06	DLKL08	DLKL10	DLKL14	DLKL20
Weight(kg)	320	390	740	1380	1700	1900	2100
Max jaw opening(m/m)	1300	1400	1800	2300	2500	2500	2700
Oil pressure(kg/cm2)	110-140	120-160	150-170	160-180	160-180	180-200	180-200
Set up pressure(kg/cm2)	170	180	190	200	210	250	250
Operating flux(l/min)	30-55	50-100	90-110	100-140	130-170	200-250	250-320
Cylinder Volume(ton)	4.0 x 2	4.5 x 2	8.0 x 2	9.7 x 2	12 x 2	12 x 2	14 x 2
Suitable excavator(ton)	4-6	7-11	12-16	17-23	24-30	31-40	41-50
