Specifications
Suitable For dry & wet materialsOutput varies 50 to 300 kg per hour
Perfect & homogenous granulation of the material
Oscillating machine
Main Structure: Main Structure of Oscillating machine fabricated from 304 grade stainless steel for GMP compliance.Complete body is mounted on a strong stainless steel base for sturdiness.
Powder Hopper: A 35 liter gross volume hopper is provided for feeding sufficient material
for process .
Rotary Assembly: The horizontal rotor assembly consists of stainless steel304 gr. Hexagonal rods
and S.S. plate with a main rotor shaft of 25mm dia S.S. the newly designed of the rotor is such that
it gives the perfect and homogenous granulation of the material. This rotor oscillates (alternately rotates in clockwise and anti clockwise direction) at approximately 48rpm.
Capacity: Actual output capacity of Oscillating machine depends upon the nature and bulk density of powder, as well as operator skill.
Grill Cover: Grill type removable cover is provided inside hopper .This grill cover protects operator from oscillating rotor and also prevents any accidental dropping of scoop etc inside operating chamber
Driving Arrangement: A TEFC electric motor of 0.75 kw power to run on 415 volts, 3 phase, 50 Hz, A.C.(other voltage on request ) is provided along with a suitable reducing gear box to get final rotating speed of 48 rpm. A D.O.L. or Star –Delta type starter will also be provided.
Discharge: Discharge from the Oscillating machine can be collected on trays (not provided with machine) that are placed on trays bars provided underneath the operating chamber.
Features:
-Suitable for production of granules from dry and wet materials.
-Gental grinding action of horizontal rotor against wire mesh gives uniform partical size.
-Wire mesh or perforated mesh can be used.
-Does not generate heat or dust, ideal for sticky heat sensitive products.
-Hopper and rotor can be easily removed for cleaning.
-Safety mesh on top of hopper and side guards are provided.
-Output varies from 50 to 300 kg per hour depending on product and screen
