Specifications
Aluminium tube filling machine-Filling volume can be set accurately
-Change parts required for different size of tubes
Plastic Tube Filling And Sealing Machine
Main machine frame with stainless steel covers
- Acrylic doors on all four sides above main frame
- Adjustable anti-vibration legs
- AC inverter for main drive for step-less speed variation
- Automatic tube hopper with pneumatic system of tube insertion into rotary index table
- Rotary index table for transferring tubes to filling, closing stations and other sections
- Tube orientation controlled by photocell for accurate positioning of tubes
- Tube cleaning by blow of compressed air inside tube
- 50 litres capacity stainless steel hopper
- Stainless steel volumetric dozing syringe and Teflon piston seals for accurate dosage with step-less adjustment of volume
- Tube lifting at filling station – so that filling nozzle gets inserted inside tube during filling
- Tail cutting by 'suck back' method to prevent dripping of product after filling
- Hot air tool for plastic / laminated tubes (Leister make heater)
- PID temperature controller for accurate control of hot air temperature
- Air supply to air heater through independent blower
- Batch code embossing facility within sealing jaws (by using negatively etched character type fount)
- Trimming of plastic / lami tubes at the top end
- Automatic tube ejection
- Preset counter
- No−Tube−No−Fill system
- Control sensor for non ejected tubes
- Safety interlock for acrylic doors
- Low air pressure switch
- Emergency stop
- Fixed position machine stop
| MODEL | OUT PUT | LOADING | EJECTING | ORIENTATION | POWER |
| ATF 2000 | 45 Tubes/min | Manual | Automatic | Manual | 1 HP |
| ATF 4000 | 80 Tubes/min | Manual | Automatic | Manual | 1.5 HP |
| ATF 6000 | 80 Tubes/min | Automatic | Automatic | Automatic | 1.5 HP |
