CE approved single aluminum alloy lift SJYL0.1-10
1. Product show:
2. Advantages
The Tilting Aluminium Alloy lifting platform has the following characteristics:
1. Lift or fall steadily: The seamless transmission is used between the lifting masts, thus minimizing the amount of away after lifting.
2. Safe and reliable: The four turning stablizers of the unit connected to the four corners of the chassis support the MEWP during work. They are designed for leveling regulation and preventing inclination. They are composed of stand bars and turning legs. The stand bars are installed in the turning legs. Extending out the turning legs before operating the unit enlarges the area of supporting. Therefore, the steadiness of the whole platform is guarranteed.
3. Convenient: The whole work platform is light because the lifting masts are made of alloy aluminum. The structure is compact and the volume is small, so only one person can move the equipment and carry it through a very narrow passage.
3. Parameter
| model | lifting height | loading capacity | table size | overall dimension | power | total weight |
| SJYL0.1-6 | 6m | 100kg | 550*550mm | 1260*800*1980mm | 1.1kw | 380kg |
| SJYL0.1-8 | 8m | 100kg | 550*550mm | 1400*850*1980mm | 1.1kw | 450kg |
| SJYL0.1-10 | 10m | 100kg | 550*550mm | 1600*870*2250mm | 1.1kw | 480kg |
Packing:
We always make the lift machine packed inner with wrap film and outer with plywood case. The plywood case is free of steaming kaori, and it is exempted from inspection products, save a lot of trouble in the process of export or import.
|
|
Shipping:
We generally quote FOB price. About the shipping, we promise to deliver goods within 7 days after receive payment. If the quantity of machine is small, we will do LCL and FCL if your order is one container. The shipping price will adjust according to the shipping.
|
|
Good service:
Jinan jinchuan company:
With a wide range, good quality, reasonable prices and stylish designs, our products are extensively used in
interior and exterior building decorations, workshops, docks, stations, supermarkets, halls, etc.
Our products are widely recognized and trusted by users and can meet continuously developing economic
and social demands.
Factory room:
Certificate:
Customers:
1. Q1: What is your MOQ?
A1: Our MOQ is 1 Set
2. Q2:Do you offer free sample?
A2:No.
3. Q3: What is your payment term?
A3: 30% down payment after confirming the contract/PI and the balance before shipment/copy of Bill of Loading.
4. Q4: What normal cooperation processes do you have?
A4:First, we need your drawing or dimension for quotation.
Second, you accept our quotation, then you pay for the tooling cost.
Third, we make sales contract for you to confirm.
Fourth, manufacturing dimention and shipping to you.
Fifth, you pay us the balance.
Finally, you receive ourlift and feedback.
If you have any questions, pls feel free to ask me, I will answer you as soon as possible. You can contact me by Skype or Email.
Skype: jinchuanlift
Email: jinchuanlift02/at/
